Danfoss VLT FC 103 Operating Instructions

Power
Size
Fuse options
Bussman
PN
Littelfuse PN Littelfuse
PN
Bussmann
PN
Siba PN Ferraz-Shawmut
PN
Ferraz-Shawmut PN
(Europe)
Ferraz-Shawmut PN
(North America)
N110 170M2619 LA50QS300-4 L50S-300 FWH-300A 20 610
31.315
A50QS300-4 6,9URD31D08A0315 A070URD31KI0315
N132 170M2620 LA50QS350-4 L50S-350 FWH-350A 20 610
31.350
A50QS350-4 6,9URD31D08A0350 A070URD31KI0350
N160 170M2621 LA50QS400-4 L50S-400 FWH-400A 20 610
31.400
A50QS400-4 6,9URD31D08A0400 A070URD31KI0400
N200 170M4015 LA50QS500-4 L50S-500 FWH-500A 20 610
31.550
A50QS500-4 6,9URD31D08A0550 A070URD31KI0550
N250 170M4016 LA50QS600-4 L50S-600 FWH-600A 20 610
31.630
A50QS600-4 6,9URD31D08A0630 A070URD31KI0630
N315 170M4017 LA50QS800-4 L50S-800 FWH-800A 20 610
31.800
A50QS800-4 6,9URD32D08A0800 A070URD31KI0800
P355 170M6013 20 630
32.900
6.9URD33D08A0900
P400 170M6013 20 630
32.900
6.9URD33D08A0900
P450 170M6013 20 630
32.900
6.9URD33D08A0900
Table 11.5 Fuse Options for 380-480 V Frequency Converters
OEM Fuse options
VLT Model Bussmann PN Siba PN Ferraz-Shawmut European PN Ferraz-Shawmut North American PN
N75k T7 170M2616 20 610 31.160 6,9URD30D08A0160 A070URD30KI0160
N90k T7 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
N110 T7 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
N132 T7 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
N160 T7 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
N200 T7 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
N250 T7 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
N315 T7 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
N400 T7 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
P450 170M4017 20 610 32.700 6.9URD31D08A0700
P500 170M4017 20 610 32.700 6.9URD31D08A0700
P560 170M6013 20 630 32.900 6.9URD33D08A0900
P630 170M6013 20 630 32.900 6.9URD33D08A0900
Table 11.6 Fuse Options for 525-690 V Frequency Converters
For UL compliance, for units supplied without a contactor-
only option, the Bussmann 170M series fuses must be
used.
Specifications Operating Instructions
MG16J202 Danfoss A/S © Rev. 05/2014 All rights reserved. 103
11 11
