Danfoss VLT FC 103 Operating Instructions

6 Programming
6.1 Introduction
The frequency converter is programmed for its application
functions using parameters. Parameters are accessed by
pressing either [Quick Menu] or [Main Menu] on the LCP.
(See chapter 5.1 Local Control Panel for details on using the
LCP function keys). Parameters may also be accessed via a
PC using the MCT 10 Set-up Software (see
chapter 6.6.1 Remote Programming with MCT 10 Set-up
Software).
The Quick Menu is intended for initial start-up (Q2-** Quick
Set-up) and detailed instructions for common frequency
converter applications (Q3-** Function Set-up). Step-by-step
instructions are provided. These instructions enable the
user to walk through the parameters used for
programming applications in their proper sequence. Data
entered in a parameter can change the options available in
the parameters following that entry. The Quick Menu
presents easy guidelines for getting most systems up and
running.
The Main Menu accesses all parameters and allows for
advanced frequency converter applications.
6.2
Programming Example
Here is an example for programming the frequency
converter for a common application in open loop using
the Quick Menu.
•
This procedure programs the frequency converter
to receive a 0-10 V DC analog control signal on
input terminal 53.
•
The frequency converter responds by providing
6-60 Hz output to the motor proportional to the
input signal (0-10 V DC=6-60 Hz).
Select the following parameters using the navigation keys
to scroll to the titles and press [OK] after each action.
1.
3-15 Reference 1 Source
5-1*
130BB848.10
3-15 Reference Resource
[
1 ]] Analog input 53
14.7% 0.00A 1(1)
References
Illustration 6.1 Programming Example Step 1
2.
3-02 Minimum Reference. Set the minimum
internal frequency converter reference to 0 Hz.
(This sets the minimum frequency converter
speed at 0 Hz).
Q3-21
130BT762.10
3-02 Minimum Reference
0.000 Hz
14.7% 0.00A 1(1)
Analog Reference
Illustration 6.2 Programming Example Step 2
3.
3-03 Maximum Reference. Set the maximum
internal frequency converter reference to 60 Hz.
(This sets the maximum frequency converter
speed at 60 Hz. Note that 50/60 Hz is a regional
variation).
Q3-21
130BT763.11
3-03 Maximum Reference
50.000 Hz
14.7% 0.00A 1(1)
Analog Reference
Illustration 6.3 Programming Example Step 3
4.
6-10 Terminal 53 Low Voltage. Set the minimum
external voltage reference on terminal 53 to 0 V.
(This sets the minimum input signal at 0 V).
Q3-21
130BT764.10
6-10 Terminal 53 Low
Voltage
0.00 V
14.7% 0.00A 1(1)
Analog Reference
Illustration 6.4 Programming Example Step 4
Programming Operating Instructions
68 Danfoss A/S © Rev. 05/2014 All rights reserved. MG16J202
66
