Danfoss VLT FC 103 Operating Instructions

2.
Scroll to parameter group 5-1* Digital Inputs and
press [OK].
130BT769.10
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
14.7% 0.00A 1(1)
Digital In/Out 5-**
Illustration 6.10 Parameter Group Display Example
3.
Scroll to 5-10 Terminal 18 Digital Input. Press [OK]
to access function choices. The default setting
Start is shown.
5-1*
130BT770.10
5-10 Terminal 18 Digital
Input
[
8 ]] Start
14.7% 0.00A 1(1)
Digital Inputs
Illustration 6.11 Function Choice Display Example
6.4 International/North American Default
Parameter Settings
Setting 0-03 Regional Settings to [0] International or [1]
North America changes the default settings for some
parameters. Table 6.1 lists those parameters that are
effected.
Parameter International default
parameter value
North American
default parameter
value
0-03 Regional
Settings
International North America
0-71 Date Format DD-MM-YYYY MM/DD/YYYY
0-72 Time Format 24 h 12 h
1-20 Motor Power
[kW]
See Note 1 See Note 1
1-21 Motor Power
[HP]
See Note 2 See Note 2
1-22 Motor Voltage 230 V/400 V/575 V 208 V/460 V/575 V
1-23 Motor
Frequency
50 Hz 60 Hz
3-03 Maximum
Reference
50 Hz 60 Hz
3-04 Reference
Function
Sum External/Preset
Parameter International default
parameter value
North American
default parameter
value
4-13 Motor Speed
High Limit [RPM]
See Note 3
1500 RPM 1800 RPM
4-14 Motor Speed
High Limit [Hz]
See Note 4
50 Hz 60 Hz
4-19 Max Output
Frequency
100 Hz 120 Hz
4-53 Warning Speed
High
1500 RPM 1800 RPM
5-12 Terminal 27
Digital Input
Coast inverse External interlock
5-40 Function Relay [2] Drive ready No alarm
6-15 Terminal 53
High Ref./Feedb.
Value
50 60
6-50 Terminal 42
Output
Output frequency Speed 4-20 mA
14-20 Reset Mode
Manual reset Infinite auto reset
22-85 Speed at
Design Point [RPM]
See Note 3
1500 RPM 1800 RPM
22-86 Speed at
Design Point [Hz]
50 Hz 60 Hz
Table 6.1 International/North American Default Parameter
Settings
Note 1: 1-20 Motor Power [kW] is only visible when 0-03 Regional
Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP], is only visible when 0-03 Regional
Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed Unit is
set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed Unit is
set to [1] Hz.
Note 5: The default value depends on the number of motor poles. For
a 4 poled motor, the international default value is 1500 RPM and for
a 2 poled motor, 3000 RPM. The corresponding values for North
America is 1800 and 3600 RPM.
Changes made to default settings are stored and available
for viewing in the Quick Menu along with any
programming entered into parameters.
1. Press [Quick Menu].
2.
Scroll to Q5 Changes Made and press [OK].
3.
Select Q5-2 Since Factory Setting to view all
programming changes or Q5-1 Last 10 Changes
for the most recent.
Programming
Operating Instructions
70 Danfoss A/S © Rev. 05/2014 All rights reserved. MG16J202
