Danfoss VLT FC 103 - Page 39

B
B
A
A
0
0.0[ ]
96
3.8[ ]
195
7.7[ ]
227
8.9[ ]
123
4.8[ ]
153
6.0[ ]
458
18.0[ ]
0
0.0[ ]
46
1.8[ ]
50
2.0[ ]
99
3.9[ ]
147
5.8[ ]
182
7.2[ ]
193
7.6[ ]
221
8.7[ ]
249
9.8[ ]
260
10.2[ ]
146
5.8[ ]
0
0.0[ ]
286
11.2[ ]
0
0.0[
113
4.4[ ]
]
206
8.1[ ]
B-B
A-A
R
S
T
U
V
W
130BC537.12
1
2
3
4
5
1 Mains terminals
2 TB6 terminal block for contactor
3 Brake terminals
4 Motor terminals
5 Ground terminals
Illustration 3.40 Terminal Locations, D6h with Contactor Option
Installation Operating Instructions
MG16J202 Danfoss A/S © Rev. 05/2014 All rights reserved. 37
3 3
