Callout Display Parameter number Default setting
1 1.1 0-20 Reference %
2 1.2 0-21 Motor current
3 1.3 0-22 Power [kW]
4 2 0-23 Frequency
5 3 0-24 kWh counter
Table 5.1 Legend to Illustration 5.1, Display Area
B. Display Menu Keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Callout Key Function
6 Status Shows operational information.
7 Quick Menu Allows access to programming
parameters for initial set-up instructions
and many detailed application
instructions.
8 Main Menu Allows access to all programming
parameters.
9 Alarm Log Displays a list of current warnings, the
last 10 alarms, and the maintenance log.
Table 5.2 Legend to Illustration 5.1, Display Menu Keys
C. Navigation Keys and Indicator Lights (LEDs)
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also
provide speed control in local (hand) operation. There are
also 3 frequency converter status indicator lights in this
area.
Callout Key Function
10 Back Reverts to the previous step or list in the
menu structure.
11 Cancel Cancels the last change or command as
long as the display mode has not
changed.
12 Info Press for a definition of the function being
displayed.
13 Navigation
keys
Press to move between items in the
menu.
14 OK Press to access parameter groups or to
enable a choice.
Table 5.3 Legend to Illustration 5.1, Navigation Keys
Callout Indicator Light Function
15 ON Green The ON light activates when the
frequency converter receives
power from mains voltage, a DC
bus terminal, or an external 24 V
supply.
16 WARN Yellow When a warning is issued, the
yellow WARN light comes on
and text appears in the display
area identifying the problem.
17 ALARM Red A fault condition causes the red
alarm light to flash and an alarm
text is displayed.
Table 5.4 Legend to Illustration 5.1, Indicator Lights (LEDs)
D. Operation Keys and Reset
Operation keys are located at the bottom of the LCP.
Callout Key Function
18 Hand On Starts the frequency converter in local
control.
•
An external stop signal by control
input or serial communication
overrides the local hand on.
19 Off Stops the motor but does not remove
power to the frequency converter.
20 Auto On Puts the system in remote operational
mode.
•
Responds to an external start
command by control terminals or
serial communication.
21 Reset Resets the frequency converter manually
after a fault has been cleared.
Table 5.5 Legend to Illustration 5.1, Operation Keys and Reset
NOTICE
The display contrast can be adjusted by pressing [Status]
and [
▲
]/[
▼
] keys.
User Interface Operating Instructions
64 Danfoss A/S © Rev. 05/2014 All rights reserved. MG16J202
