9.5 Active Filter Warning and Alarm Definitions
NOTICE
After a manual reset pressing [Reset], press [Auto On] or [Hand On] to restart the unit.
If an alarm cannot be reset, the reason may be that its cause has not been rectified, or the alarm is trip-locked (see also
Table 9.3).
Alarms that are trip-locked offer additional protection, meaning that the mains supply must be switched off before the
alarm can be reset. After being switched back on, the unit is no longer blocked and may be reset as described above once
the cause has been rectified.
Alarms that are not trip-locked can also be reset using the automatic reset function in 14-20 Reset Mode (Warning: automatic
wake-up is possible)
If a warning and alarm is marked against a code in Table 9.3, either a warning occurs before an alarm, or it can be specified
whether it is a warning or an alarm that is to be displayed for a given fault.
No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
1 10 Volts low X
2 Live zero error (X) (X) 6-01
4 Mains phase loss X
5 DC link voltage high X
6 DC link voltage low X
7 DC over voltage X X
8 DC under voltage X X
13 Over current X X X
14 Earth fault X X X
15 Hardware mismatch X X
16 Short circuit X X
17 Control word timeout (X) (X) 8-04
23 Internal fan fault X
24 External fan fault X 14-53
29 Heatsink temp X X X
33 Inrush fault X X
34 Fieldbus fault X X
35 Option fault X X
38 Internal fault
39 Heatsink sensor X X
40 Overload of digital output terminal 27 (X) 5-00, 5-01
41 Overload of digital output terminal 29 (X) 5-00, 5-02
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
65 Control board over-temperature X X X
66 Heat sink temperature low X
67 Option configuration has changed X
68 Safe torque off activated
X
1)
69 Pwr. card temp X X
70 Illegal FC configuration X
72 Dangerous Failure
X
1)
73 Safe torque off auto restart
76 Power unit setup X
Warnings and Alarms Operating Instructions
MG37A202 Danfoss A/S © Rev. 2014-07-29 All rights reserved. 131
