Danfoss VLT FC 302 User Manual

6.3.24 35-** Sensor Input Option
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
35-0* Temp. Input Mode
35-00 Term. X48/4 temp. unit [60] °C All set-ups TRUE - Uint8
35-01 Term. X48/4 input type [0] Not Connected All set-ups TRUE - Uint8
35-02 Term. X48/7 temp. unit [60] °C All set-ups TRUE - Uint8
35-03 Term. X48/7 input type [0] Not Connected All set-ups TRUE - Uint8
35-04 Term. X48/10 temp. unit [60] °C All set-ups TRUE - Uint8
35-05 Term. X48/10 input type [0] Not Connected All set-ups TRUE - Uint8
35-06
Temperature sensor alarm
function [5] Stop and trip All set-ups TRUE - Uint8
35-1* Temp. Input X48/4
35-14
Term. X48/4 filter time
constant 0.001 s All set-ups TRUE -3 Uint16
35-15 Term. X48/4 temp. monitor [0] Disabled All set-ups TRUE - Uint8
35-16 Term. X48/4 low temp. limit App.Dependent All set-ups TRUE 0 Int16
35-17 Term. X48/4 high temp. limit App.Dependent All set-ups TRUE 0 Int16
35-2* Temp. Input X48/7
35-24
Term. X48/7 filter time
constant 0.001 s All set-ups TRUE -3 Uint16
35-25 Term. X48/7 temp. monitor [0] Disabled All set-ups TRUE - Uint8
35-26 Term. X48/7 low temp. limit App.Dependent All set-ups TRUE 0 Int16
35-27 Term. X48/7 high temp. limit App.Dependent All set-ups TRUE 0 Int16
35-3* Temp. Input X48/10
35-34
Term. X48/10 filter time
constant 0.001 s All set-ups TRUE -3 Uint16
35-35 Term. X48/10 temp. monitor [0] Disabled All set-ups TRUE - Uint8
35-36 Term. X48/10 low temp. limit App.Dependent All set-ups TRUE 0 Int16
35-37 Term. X48/10 high temp. limit App.Dependent All set-ups TRUE 0 Int16
35-4* Analog Input X48/2
35-42 Term. X48/2 low current 4.00 mA All set-ups TRUE -5 Int16
35-43 Term. X48/2 high current 20.00 mA All set-ups TRUE -5 Int16
35-44
Term. X48/2 low ref./feedb.
value 0.000 N/A All set-ups TRUE -3 Int32
35-45
Term. X48/2 high ref./feedb.
value 100.000 N/A All set-ups TRUE -3 Int32
35-46
Term. X48/2 filter time
constant 0.001 s All set-ups TRUE -3 Uint16
6.4 Parameter Lists - Active Filter
6.4.1 Operation/Display 0-**
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
0-0* Basic Settings
0-01 Language [0] English 1 set-up TRUE - Uint8
0-04
Operating state at power-up
(hand) [1] Forced stop All set-ups TRUE - Uint8
0-1* Set-up Operations
Programming Operating Instructions
106 Danfoss A/S © Rev. 2014-07-29 All rights reserved. MG37A202
66

Danfoss VLT FC 302 Specifications

General

Brake Function	Built-in brake chopper in all units up to 22 kW
Output Voltage Range	0-100% of input voltage
Power Range	0.37 kW
Control Modes	VVCplus, Flux, U/f
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature, overload
Communication Options	Modbus RTU, BACnet, Ethernet/IP, Profinet, Profibus, CANopen, DeviceNet
Ambient Temperature Range	-10°C to +50°C (derating above +40°C)
Enclosure Rating	IP20, IP21, IP55
Cooling Method	Air-cooled
Input Voltage	200-240V, 380-480V, 525-600V
