Danfoss VLT FC 302 User Manual

P315 P355 P400 P450
Normal Overload =110% current for 60 s NO NO NO NO
Typical shaft output at 400 V [kW] 315 355 400 450
Typical shaft output at 460 V [hp] 450 500 600 600
Typical shaft output at 480 V [kW] 355 400 500 530
Enclosure IP21/54 E9
Output current
Continuous (at 400 V) [A] 600 658 745 800
Intermittent (60 s overload) (at 400 V) [A] 660 724 820 880
Continuous (at 460/480 V) [A] 540 590 678 730
Intermittent (60 s overload) (at 460/480 V)
[A]
594 649 746 803
Continuous kVA (at 400 V) [kVA] 416 456 516 554
Continuous kVA (at 460 V) [kVA] 430 470 540 582
Continuous kVA (at 480 V) [kVA] 468 511 587 632
Max. Input current
Continuous (at 400 V) [A] 590 647 733 787
Continuous (at 460/480 V) [A] 531 580 667 718
Max. pre-fuses
1)
[A]
700 900
Max. cable size
Motor (mm
2
/AWG
2)
)
4x240 (4x500 mcm)
Mains (mm
2
/AWG
2)
)
Brake (mm
2
/AWG
2)
)
2x185 (2x350 mcm)
Total LHD loss 400 V AC [kW] 14051 15320 17180 18447
Total back channel loss 400 V AC [kW] 11301 11648 13396 14570
Total filter loss 400 V AC [kW] 7346 7788 8503 8974
Total LHD loss 460 V AC [kW] 12936 14083 15852 16962
Total back channel loss 460 V AC [kW] 10277 10522 12184 13214
Total filter loss 460 V AC [kW] 7066 7359 8033 8435
Weight, enclosure IP21, IP54 [kg] 596 623 646
Efficiency
4)
0.96
Output frequency [Hz] 0-600
Heatsink overtemp. trip [°C] 105
Power card ambient trip [°C] 85
*High overload = 160% torque during 60 s; Normal overload = 110% torque during 60 s
Table 11.2 Mains Supply 3x380-480 V AC
