Danfoss VLT FC Series Service Guide

1
3
4
2
130BF940.10
1 AC input busbar 3 Brake/regen terminals (optional)
2 Input terminals 4 Output terminals
Illustration 8.11 Power Terminals in E-sized Drives
Whenever possible, perform these procedures with a split bus power supply. For more information, see
chapter 9.1.1 Overview.
Test Procedures
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
106 Danfoss A/S © 02/2019 All rights reserved. MG94A502
88

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
