10.2.10 Mixing Fan
The mixing fan snaps into a slot in the power terminal
mounting plate. To remove or reinstall the mixing fan, use
the following steps. See Illustration 10.7.
Disassembly
1. Place the end of a screwdriver under each of the
mixing fan release tabs. Press in and lift to free
the fan and housing from the power terminal
mounting plate.
2. Unplug the mixing fan cable connector. Tape the
free end of the fan cable to the mounting plate
so that it does not fall back into the drive.
3. Remove the mixing fan from the fan housing.
Reassembly
1. Connect the fan cable to the mixing fan cable
connector.
2. Position the mixing fan in the fan housing.
3. Position the fan and housing in the fan slot on
the power terminal mounting plate.
4. Press the mixing fan into the slot until the release
tabs snap into place.
D1h/D3h/D5h/D6h/J8 Drive Di...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
142 Danfoss A/S © 02/2019 All rights reserved. MG94A502
