SMPS
POWER CARD
Split Bus Connector (MK901)
650 V DC
24 V DC
DC Bus Connector (MK902)
130BF085.10
SPLIT BUS POWER SUPPLY (130B4146)
Illustration 9.2 Connection During Split Bus Mode for a Single Drive
SMPS
POWER CARD
Split Bus Connector (MK901)
SERVICE KIT
CONTROL
CARD
MDCIC
650 V DC
24 V DC
DC Bus Connector (MK902)
130BF086.10
SPLIT BUS POWER SUPPLY (130B4146)
MK 111
MK102
A C
44-Pin
Ribbon
Cable
LCP
(+) (-)
(+) (-)
44-Pin
Ribbon
Cable
Illustration 9.3 Connection During Split Bus Mode in Parallel Drive
Special Test Equipment Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 121
9 9
