Danfoss VLT FC Series Service Guide

1
2
3
4
6
9
10
7
8
5
e30bg396.10
1 Captive screws (T25) 6 Heat sink fan
2 Mounting studs 7 Heat sink fan cable connector
3 Hole for cable grommet 8 Cable grommet
4 Slots for heat sink fan cover 9 Heat sink fan cover
5 Mounting holes 10 Fan cover tabs
Illustration 10.24 Heat Sink Fan in IP21/IP54 (UL type 1/12) Drives
D1h/D3h/D5h/D6h/J8 Drive Di...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
172 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1010

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
