Danfoss VLT FC Series

Power
rating
Drive type Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N110 H D1h/D3h D5h/D6h –
N132 H D1h/D3h D5h/D6h –
N160 H D1h/D3h D5h/D6h –
N200 H D2h/D4h D7h/D8h –
N250 H D2h/D4h D7h/D8h –
N315 H D2h/D4h D7h/D8h –
N315 P6/P8 Db2 – 2-module system
N355 P6/P8 Db2 – 2-module system
N355 H E1h/E3h – –
N400 P6/P8 Db2 – 2-module system
N400 H E1h/E3h – –
N450 P6/P8 Db2 – 2-module system
N450 H E1h/E3h – –
N500 P2/P4 Da2 – 2-module system
N500 P6/P8 Db2 – 2-module system
N500 H E2h/E4h – –
N560 P2/P4 Da4 – 4-module system
N560 P6/P8 Db4 – 4-module system
N560 H E2h/E4h – –
N630 P2/P4 Da4 – 4-module system
N630 P6/P8 Db4 – 4-module system
N710 P2/P4 Da4 – 4-module system
N710 P6/P8 Db4 – 4-module system
N800 P2/P4 Da4 – 4-module system
N800 P6/P8 Db4 – 4-module system
N1000 P2/P4 Da4 – 4-module system
N1000 P6/P8 Db4 – 4-module system
Table 3.6 380–480 V AC (T4) Voltage Rating for FC 102, FC 103, and FC 202
Power
rating
Drive type Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N90K H J8 – –
N110 H J8 – –
N132 H J8 – –
N160 H J8 – –
N200 H J9 – –
N250 H J9 – –
N315 H J9 – –
Table 3.7 380–480 V AC (T4) Voltage Rating for FC 361
Product Overview
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
18 Danfoss A/S © 02/2019 All rights reserved. MG94A502
