Danfoss VLT FC Series Service Guide

1
7
8
10
12
6
5
11
9
4
2
3
130BF857.10
1 MK1802 7 Inrush card
2 MK1800 8 Screw (T20)
3 Screw (T20) 9 MK101
4 MK102 10 Gate drive card
5 MK100 11 MK701
6 MK501 12 MK601
Illustration 11.8 Gate Drive Card and Inrush Card
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
206 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1111

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
