Danfoss VLT FC Series Service Guide

Power
rating
Drive
type
Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N55K H D1h/D3h D5h/D6h –
N75K H D1h/D3h D5h/D6h –
N90K H D1h/D3h D5h/D6h –
N110 H D1h/D3h D5h/D6h –
N132 H D1h/D3h D5h/D6h –
N160 H D2h/D4h D7h/D8h –
N200 H D2h/D4h D7h/D8h –
N250 H D2h/D4h D7h/D8h –
N250 P6 Db2 – 2-module system
N315 H D2h/D4h D7h/D8h –
N315 P6 Db2 – 2-module system
N355 P6 Db2 – 2-module system
N355 H E1h/E3h – –
N400 P6 Db2 – 2-module system
N400 H E1h/E3h – –
N500 P6 Db2 – 2-module system
N500 H E1h/E3h – –
N560 P6 Db2 – 2-module system
N560 H E1h/E3h – –
N630 P2 Da4 – 4-module system
N630 P6 Db4 – 4-module system
N630 H E2h/E4h – –
N710 P2 Da4 – 4-module system
N710 P6 Db4 – 4-module system
N710 H E2h/E4h – –
N800 P2 Da4 – 4-module system
N800 P6 Db4 – 4-module system
N900 P2 Da4 – 4-module system
N900 P6 Db4 – 4-module system
N1M0 P2 Da4 – 4-module system
N1M0 P6 Db4 – 4-module system
Table 3.10 525–690 V AC (T7) Voltage Rating for FC 302
Product Overview Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 21
3 3

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
