Danfoss VLT FC Series Service Guide

1
2
3
4
5
6
7
8
130BF839.10
1 Screw (T40) 5 Horizontal brake busbars
2 R(-) vertical brake busbar 6 Screw (T40)
3 Nut (13 mm) 7 R(+) vertical brake busbar
4 Screw (T40) 8 Screw (T40)
Illustration 13.31 Brake Busbars
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
312 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1313
