Danfoss VLT Micro Drive FC 51 Programming Guide

5 Parameter Lists
50
5.1.1 Conversion Index 54
5.1.2 Change during operation 54
5.1.3 2-Set-up 54
5.1.4 Type 54
5.1.5 0-** Operation/Display 55
5.1.6 1-** Load/Motor 56
5.1.7 2-** Brakes 57
5.1.8 3-** Reference/Ramps 57
5.1.9 4-** Limits/Warnings 58
5.1.10 5-** Digital In/Out 58
5.1.11 6-** Analog In/Out 59
5.1.12 7-** Controllers 59
5.1.13 8-** Comm. and Options 60
5.1.14 13-** Smart Logic 60
5.1.15 14-** Special Functions 61
5.1.16 15-** Drive Information 61
5.1.17 16-** Data Readouts 62
6 Troubleshooting
63
6.1.1 Alarm, Warning and Extended Status Word 65
Index
69
Contents
VLT
®
Micro Drive FC 51 Programming Guide
2 MG02C602 - VLT
®
is a registered Danfoss trademark
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
