Danfoss VLT Micro Drive FC 51 Programming Guide

5.1.17 16-** Data Readouts
Parameter
Number
Parameter Description Default Value 2 Setup
Change During
Operation
Conversi
on
Index
Type
16-00 Control Word 0 1 set-up TRUE 0 Uint16
16-01 Reference [Unit] 0 1 set-up TRUE -3 Int32
16-02 Reference % 0 1 set-up TRUE -1 Int16
16-03 Status Word 0 1 set-up TRUE 0 Uint16
16-05 Main Actual Value [%] 0 1 set-up TRUE -2 Int16
16-09 Custom Readout 0 1 set-up TRUE -2 Int32
16-10 Power [kW] 0 1 set-up TRUE -3 Uint16
16-11 Power [hp] 0 1 set-up TRUE -3 Uint16
16-12 Motor Voltage 0 1 set-up TRUE 0 Uint16
16-13 Frequency 0 1 set-up TRUE -1 Uint16
16-14 Motor Current 0 1 set-up TRUE -2 Uint16
16-15 Frequency [%] 0 1 set-up TRUE -1 Uint16
16-18 Motor Thermal 0 1 set-up TRUE 0 Uint8
16-30 DC Link Voltage 0 1 set-up TRUE 0 Uint16
16-34 Heatsink Temp. 0 1 set-up TRUE 0 Uint8
16-35 Inverter Thermal 0 1 set-up TRUE 0 Uint8
16-36 Inv. Nom. Current 0 1 set-up TRUE -2 Uint16
16-37 Inv. Max. Current 0 1 set-up TRUE -2 Uint16
16-38 SL Controller State 0 1 set-up TRUE 0 Uint8
16-50 External Reference 0 1 set-up TRUE -1 Int16
16-51 Pulse Reference 0 1 set-up TRUE -1 Int16
16-52 Feedback [Unit] 0 1 set-up TRUE -3 Int32
16-60 Digital input 18,19,27,33 0 1 set-up TRUE 0 Uint16
16-61 Digital input 29 0 1 set-up TRUE 0 Uint8
16-62 Analog Input 53 (V) 0 1 set-up TRUE -2 Uint16
16-63 Analog Input 53 (mA) 0 1 set-up TRUE -2 Uint16
16-64 Analog Input 60 0 1 set-up TRUE -2 Uint16
16-65 Analog Output 42 [mA] 0 1 set-up TRUE -2 Uint16
16-68 Pulse input 33 20 1 set-up TRUE 0 Uint16
16-71 Relay Output [bin] 0 1 set-up TRUE 0 Uint8
16-72 Counter A 0 1 set-up TRUE 0 Int16
16-73 Counter B 0 1 set-up TRUE 0 Int16
16-86 FC Port REF 1 0 1 set-up TRUE 0 Int16
16-90 Alarm Word 0 1 set-up TRUE 0 Uint32
16-92 Warning Word 0 1 set-up TRUE 0 Uint32
16-94 Ext. Status Word 0 1 set-up TRUE 0 Uint32
Table 5.20
Parameter Lists
VLT
®
Micro Drive FC 51 Programming Guide
62 MG02C602 - VLT
®
is a registered Danfoss trademark
55
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
