Danfoss VLT Micro Drive FC 51 Programming Guide

5.1.9 4-** Limits/Warnings
Parameter
Number
Parameter Description Default Value 2 Setup
Change During
Operation
Conversi
on
Index
Type
4-10 Motor Speed Direction [2] Both directions All set-ups FALSE - Uint8
4-12 Motor Speed Low Limit [Hz] 0 Hz All set-ups FALSE -1 Uint16
4-14 Motor Speed High Limit [Hz] 65 Hz All set-ups FALSE -1 Uint16
4-16 Torque Limit Motor Mode 150% All set-ups TRUE 0 Uint16
4-17 Torque Limit Generator Mode 100% All set-ups TRUE 0 Uint16
4-40 Warning Frequency Low 0Hz All set-ups TRUE -1 Uint16
4-41 Warning Frequency High 400Hz All set-ups TRUE -1 Uint16
4-50 Warning Current Low 0 A All set-ups TRUE -2 Uint32
4-51 Warning Current High 26 A All set-ups TRUE -2 Uint32
4-54 Warning Reference Low -4999 All set-ups TRUE -3 Int32
4-55 Warning Reference High 4999 All set-ups TRUE -3 Int32
4-56 Warning Feedback Low -4999 All set-ups TRUE -3 Int32
4-57 Warning Feedback High 4999 All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function [1] On All set-ups FALSE - Uint8
4-61 Bypass Speed From [Hz] 0 Hz All set-ups TRUE -1 Uint16
4-63 Bypass Speed To [Hz] 0 Hz All set-ups TRUE -1 Uint16
Table 5.12
5.1.10 5-** Digital In/Out
Parameter
Number
Parameter Description Default Value 2 Setup
Change During
Operation
Conversi
on
Index
Type
5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 Digital Input [10] Reversing All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input [1] Reset All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input [14] Jog All set-ups TRUE - Uint8
5-15 Terminal 33 Digital Input [16] Preset ref bit 0 All set-ups TRUE - Uint8
5-34 On Delay, Terminal 42 Digital Output 0.01s All set-ups TRUE -2- Uint16
5-35 Off Delay, Terminal 42 Digital Output 0.01s All set-ups TRUE -2 Uint16
5-40 Function Relay [0] No operation All set-ups TRUE - Uint8
5-41 On Delay, Relay 0.01s All set-ups TRUE -2 Uint16
5-42 Off Delay, Relay 0.01s All set-ups TRUE -2 Uint16
5-55 Terminal 33 Low Frequency 20 Hz All set-ups TRUE 0 Uint16
5-56 Terminal 33 High Frequency 5000 Hz All set-ups TRUE 0 Uint16
5-57 Terminal 33 Low Ref./Feedb. Value 0 All set-ups TRUE -3 Int32
5-58 Terminal 33 High Ref./Feedb. Value 50 All set-ups TRUE -3 Int32
Table 5.13
Parameter Lists
VLT
®
Micro Drive FC 51 Programming Guide
58 MG02C602 - VLT
®
is a registered Danfoss trademark
55
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
