4.9 Parameter Group 8: Communication
4.9.1 8-** Communication
Parameter group for configuring communication.
4.9.2 8-0* General Settings
Use this parameter group for configuring the general
settings
for communication.
8-01 Control Site
Option: Function:
[0] * Digital and
Control
Word
Use both digital input and control word
as control.
[1] Digital Only Use digital input as control.
[2] Control Word
Only
Use control word only as control.
NOTE
The
setting in this parameter
overrules settings in 8-50 Coasting
Select to 8-56 Preset Reference Select.
8-02 Control Word Source
Option: Function:
[0] None Function is inactive
[1] * FC RS-485 Monitoring control word source is done via
serial
communication port RS-485.
8-03 Control Word Timeout Time
Range: Function:
1.0 s* [0.1-6500 s] Enter time to pass before control word
timeout
function (8-04 Control Word Timeout
Function) must be carried out.
8-04 Control Word Timeout Function
Option: Function:
Select the action to be taken in case of a
timeout.
[0] * Off No function.
[1] Freeze Output Freeze output until communication
resumes.
[2] Stop Stop with auto restart when communication
resumes.
[3] Jogging Run motor at jog frequency until communi-
cation
resumes.
[4] Max. Speed Run motor at max. frequency until
communication
resumes.
[5] Stop and Trip Stop motor, then reset frequency converter
in
order to restart either via LCP or digital
input.
8-06 Reset Control Word Timeout
Option: Function:
Resetting the control word timeout will
remove
any timeout function.
[0] * No Function Control word timeout is not reset.
[1] Do Reset Control word timeout is reset, and parameter
goes
into [0] No Function state.
4.9.3 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option: Function:
Select the protocol to be used. Note that
changing
protocol will not be effective until
after powering off the frequency converter.
[0] * FC
[2] Modbus RTU
8-31 Address
Range: Function:
Select the address for the bus.
1* [1 - Protocol-dependent] FC-bus range is 1-126.
Modbus
range is 1-247.
8-32 FC Port Baud Rate
Option: Function:
Select baud rate for FC Port.
NOTE
Changing
baud rate will be effective after
responding to any ongoing bus-requests.
[0] 2400 Baud
[1] 4800 Baud
[2] * 9600 Baud When choosing FC bus in 8-30
[3] * 19200 Baud When choosing Modbus in 8-30
[4] 38400 Baud
8-33 FC Port Parity
Option: Function:
This parameter only affects Modbus
as
FC bus always has even parity.
[0] * Even Parity (1 stopbit)
[1] Odd parity
[2] No Parity (1 stopbit) Select this for Modbus RTU
[3] No Parity (2 stopbit)
8-35 Minimum Response Delay
Range: Function:
0.010 s* [0.001-0.500 s] Specify minimum delay time between
receiving
a request and transmitting a
response.
Parameter Descriptions
VLT
®
Micro Drive FC 51 Programming Guide
MG02C602 - VLT
®
is a registered Danfoss trademark
37
4 4
