16-51 Pulse Reference
Range: Function:
0.0 %* [-200.0-200.0%] View actual pulse input converted to a
reference
in percent.
16-52 Feedback
Range: Function:
0.000* [-4999.000-4999.000] View analog or pulse feedback in
Hz.
4.13.4 16-6* Inputs and Outputs
16-60 Digital Input 18, 19, 27, 33
Range: Function:
0* [0-1111] View signal states from active digital inputs.
16-61 Digital Input 29
Range: Function:
0* [0-1] View signal state on digital input 29.
16-62 Analog Input 53 (volt)
Range: Function:
0.00* [0.00-10.00 V] View input voltage on analog input
terminal.
16-63 Analog Input 53 (current)
Range: Function:
0.00* [0.00-20.00 mA] View input current on analog input
terminal.
16-64 Analog Input 60
Range: Function:
0.00* [0.00-20.00 mA] View actual value at input 60 either as
reference
or protection value.
16-65 Analog Output 42 [mA]
Range: Function:
0.00 mA* [0.00-20.00 mA] View output current on analog
output
42.
16-68 Pulse Input
Range: Function:
20 Hz* [20-5000 Hz] View input frequency on pulse input
terminal.
16-71 Relay Output [bin]
Range: Function:
0* [0-1] View relay setting.
16-72 Counter A
Range: Function:
0* [-32768-32767] View present value of Counter A.
16-73 Counter B
Range: Function:
0* [-32768-32767] View present value of Counter B.
4.13.5 16-8* FC Port
Parameter for viewing references from FC Port.
16-86 FC Port REF 1
Range: Function:
0* [0x8000-0x7FFF] View currently received reference from FC
Port.
4.13.6 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range: Function:
0* [0-0xFFFFFFFF] Via alarm word sent via serial communi-
cation
port in hex code.
16-92 Warning Word
Range: Function:
0* [0-0xFFFFFFFF] View warning word sent via serial communi-
cation
port in hex code.
16-94 Ext. Status Word
Range: Function:
0* [0-0xFFFFFFFF] View extended warning word sent via serial
communication
port in hex code.
Parameter Descriptions
VLT
®
Micro Drive FC 51 Programming Guide
MG02C602 - VLT
®
is a registered Danfoss trademark
49
4 4
