No. Description Warning Alarm Trip Lock Error Parameter
Reference
51 AMT check U
nom
and I
nom
X
52 AMT low I
nom
X
53 AMT motor too big X
54 AMT motor too small X
55 AMT Parameter out of range X
59 Current limit X
63 Mechanical Brake Low X
80 Drive Initialized to Default Value X
84 The connection between drive and LCP is lost X
85 Button disabled X
86 Copy fail X
87 LCP data invalid X
88 LCP data not compatible X
89 Parameter read only X
90 Parameter database busy X
91 Parameter value is not valid in this mode X
92 Parameter value exceeds the min/max limits X
Table 6.1 Alarm/Warning Code List
(X) Dependent on parameter
A
trip is the action when an alarm has appeared. The trip
will coast the motor and can be reset by pressing [Reset]
or make a reset by a digital input (parameter group 5-1*
[1]). The original event that caused an alarm cannot
damage the frequency converter or cause dangerous
conditions. A trip lock is an action when an alarm occurs,
which may cause damage to frequency converter or
connected parts. A trip lock situation can only be reset by
a power cycling.
LED indication
Warning yellow
Alarm flashing red
Table 6.2
The
alarm words, warning words and extended status
words can be read out via serial bus or optional fieldbus
for diagnosis. See also 16-90 Alarm Word, 16-92 Warning
Word and 16-94 Ext. Status Word.
Troubleshooting
VLT
®
Micro Drive FC 51 Programming Guide
64 MG02C602 - VLT
®
is a registered Danfoss trademark
