Danfoss VLT Micro Drive FC 51 User Manual

e30ba473.10
Com RS 485
P RS 485
N RS 485
+24 V OUT
A IN
D IN D IN D IN D IN D IN
Start
Reverse
Reset
Jog
Preset bit 0
GND
0/4 - 20 mA Output
A OUT
GND
0 -10 V A IN
1K Ohm
+10 V OUT
0/4 - 20 mA Input
+24 V GND GND PNU 5 - 10 PNU 5 - 11 PNU 5 - 12 PNU 5 - 13 PNU 5 - 15 PNU 6 - 9* PNU 6 - 1* PNU 6 - 2* +10 V DC
61
68 69
12 18
19 20
27
29 33
42
50 53 55
60
Illustration 5: Overview of Control Terminals in PNP-conguration with Factory Setting
AQ348848915086en-000101 / 130R094314 | Danfoss A/S © 2020.09
Installation
VLT® Micro Drive FC 51
Operating Guide
