5.1.3 Accessory Bags
Frame sizes A1, A2 and A3 Frame size A5 Frame sizes B1 and B2 Frame sizes C1 and C2
Frame size B3 Frame size B4 Frame size C3 Frame size C4
1 + 2 only available in units with brake chopper. For DC link connection (Load sharing) the connector 1 can be ordered separately (Code no. 130B1064)
An eight pole connector is included in accessory bag for FCR 103 without Safe Stop.
Table 5.5 Accessory Bags: Find the Following Parts included in the Frequency Converter Accessory Bags
