VLT
®
2800 Series
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
500 Address 1 No 0 5
501 Baudrate 9600 B aud No 0 5
502 Coasting stop Logic or Yes 0 5
503 Quick stop Logic or Yes 0 5
504 DC brake Logic or Yes 0 5
505 Start Logic or Yes 0 5
506 Reversing Logic or Yes 0 5
507 Selection of Setup Logic or Yes 0 5
508 Selection of preset ref. Logic or Yes 0 5
509 Bus jog 1 10.0 Hz Yes -1 6
510 Bus jog 2 10.0 Hz Yes -1 6
512 Teleg ram profile FC protocol Yes 0 5
513 Bu s time interval 1 sec. Ye s 0 5
514 Bu s time interval function Off Yes 0 5
515 Data readout: Reference % No -1 3
516 Data readout: Reference [unit] No -3 4
517 Data readout: Feedback [unit] No -3 4
518 Data readout: Frequency No -1 3
519 Da ta re adout: Frequency x s caling No -1 3
520 Data read o ut: Motor current No -2 7
521 Da ta readout: Torque No -1 3
522 Data readout: Power [kW] No 1 7
523 Data readout: Power [HP] No -2 7
524 Data r ea dout: Motor voltage [V] No -1 6
525 Data readout: DC Link voltage No 0 6
526 Da ta readout: Motor therm al load No 0 5
527 Data readout: Inverter thermal load No 0 5
528 Da ta readout: Digital input No 0 5
529 Data readout: Analogue input, term. 53 No -1 5
531 Data readout: Analogue input, term. 60 No -4 5
532 Data readout: Pulse reference No -1 7
533 Data readout: External reference No -1 6
534 Da ta readout: Status w ord No 0 6
535 Data readout: Bus feedback 1 No 0 3
537 Data readout: Inverter temperature No 0 5
538 Data readout: Alarm word No 0 7
539 Data readout: Control word No 0 6
540 Data re ad o ut: Warning word No 0 7
541 Data readout: Extended status word No 0 7
544 Data readout: Pulse count No 0 7
