VLT
®
2800 Series
key has been pushed. The display indicates
when copying is in progress.
007 LCP copy
(LCP COPY)
Value:
✭No copying (NO COPY)
[0]
Up load all p arameters (UPL. ALL PAR.)
[1]
Download all parameters (D WN L . ALL PAR.)
[2]
Download size-independent parameters
(DWNL.OUTPIND.PAR.)
[3]
Function:
Parameter 007 LCP copy is used if you want to use
the LCP 2 control panel’s integral copy function. The
function is used if you want to copy all parameter
setups from one frequency converter to another
by moving the LCP 2 control panel.
Description of choice:
Select Upload all parameters [1] if you want all
parameter values to be transferred to the control
panel. Select D ownload all parameters [2] if all
parameter values transferred are to be copied to the
frequency converter to which the control panel is
attached. Select Download size-independent par. [3]
if you only want to d ownl oade the size-independent
parameters. T his is used when downloading to a
frequency c onverter with a different rated power size
than that from whic h the parameter setup originates.
NB!:
Upload/download can only be performed
in stop mode. Download can o
nly be
performed to a frequency converter with
the same software version number, see parameter
626 Database identification no.
008 Display scaling of output frequency
(FREQUENCY SCALE)
Value:
0.01 - 100.00
✭ 1.00
Function:
In this parameter, the factor is selected by which the
output frequency is to be multiplied. The value is shown
in the display, provided parameters 009-012 Disp
lay
readout have been set to O utput frequency x scaling [5].
Description of choice:
Set the required scaling factor.
009 Large display readout
(DISPLAY LINE 2)
Value:
No readout (NONE)
[0]
Resulting reference [%]
(REFERENCE [%])
[1]
Resulting reference [unit]
(REFERENCE [UNIT])
[2]
Feedback [unit] (FEEDBACK [UNIT])
[3]
✭Frequency [Hz] (FREQUENCY [HZ])
[4]
Output frequency x scaling
(FREQUENCY X SCALE)
[5]
Motor current [A] (MOTOR CURRENT [A])
[6]
Torq ue [%] (TORQUE [%])
[7]
Power [kW] (POWER [KW])
[8]
Power [HP] (POWER [HP][US])
[9]
Motor voltage [V]
(MOTOR VOLTAGE [V])
[11]
DC link voltage [V]
(DC LINK VOLTAGE [V])
[12]
Thermal load motor [%]
(MOTOR THERMAL [%])
[13]
Thermal load [%]
(FC. THERMAL[%])
[14]
Running hours [Hours]
(RUNNING HOURS])
[15]
Digital input [Bin]
(DIGITA L INPUT[BIN])
[16]
Analog input 53 [V]
(ANALOG INPU T 53 [V])
[17]
Analog input 60 [mA]
(ANALOG INPUT 60 [MA])
[19]
Pulse reference [Hz]
(PULSE REF. [HZ])
[20]
External refere nce [%]
(EXTERNAL REF. [%])
[21]
Status word [Hex] ( STATUS WORD [HEX])
[22]
Heatsink temperature [°C]
(HEATSINK TEMP [°C])
[25]
Alarm word [Hex] (ALARM WORD [HEX])
[26]
Control word [Hex] (CONTROL WORD [HEX])
[27]
Warning word [Hex]
(WARNING WORD [HEX])
[28]
Extended status word [Hex]
(EXT. STATUS [HEX])
[29]
Communication option card warning
(CO MM OPT WARN [HEX])
[30]
Pulse count
(PULSE COUNTER)
[31]
Function:
In this parameter you can select the data value that
you wish to display in the LCP 2 control unit display
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.E9.02 - VLT is a registered Danfoss trademark
62
