Technical specications
Capacity at ARI rating conditions - High pressure ratio - VZH088AH - VZH117AH - VZH170AH
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088AH*
1500 rpm
25
20 - 5700 7100 8600 10400 12500 14900 - -
30 - 5200 6500 7900 9700 11600 13900 16400 19200
40 - 4600 5800 7200 8800 10700 12700 15000 17600
50 - - 5100 6400 7800 9500 1130 0 13400 15800
60 - - - - 6600 8100 9700 11600 13600
68 - - - - - - - - -
3600 rpm
60
20 12000 14700 17900 21700 26100 31200 37100 - -
30 10600 13100 16200 19700 23900 28600 34100 40300 47300
40 - 11700 14600 17800 21600 26000 31000 36800 43200
50 - - 12900 15800 19300 23200 27700 32900 38800
60 - - - - 16600 20100 24100 28700 34000
68 - - - - - - 21300 25600 30400
6000 rpm
100
20 - 24000 29200 35400 42700 51100 60700 - -
30 - 21800 26800 32700 39500 47400 56400 66700 78300
40 - 19800 24400 29800 36100 43300 51600 61000 71700
50 - - 21800 26600 32200 38700 46100 54600 64200
60 - - - - 27900 33500 40000 47400 55900
68 - - - - - - - - -
VZH117AH*
1500 rpm
25
20 - 7700 9500 11600 14000 16800 20000 - -
30 - 6900 8700 10700 13000 15600 18600 22000 25800
40 - 6100 7800 9700 11900 14300 17100 20200 23700
50 - - 6800 8500 10500 12700 15200 18000 21200
60 - - - - 8900 10800 13100 15500 18300
68 - - - - - - - - -
3600 rpm
60
20 16200 19800 24000 29100 35000 41900 49700 - -
30 14200 17600 21700 26500 32000 38500 45800 54100 63600
40 - 15700 19500 23900 29100 34900 41700 49300 58000
50 - - 17300 21300 25800 31100 37200 44100 52000
60 - - - - 22300 27000 32400 38500 45600
68 - - - - - - 28700 34300 40800
6000 rpm
100
20 - 32300 39200 47500 57300 68500 81500 - -
30 - 29300 36000 43900 53000 63600 75700 89500 105100
40 - 26500 32800 40000 48500 58200 69300 81900 96200
50 - - 29200 35800 43300 52000 61900 73300 86200
60 - - - - 37400 45000 53600 63600 75000
68 - - - - - - - - -
VZH170AH*
1500 rpm
25
20 - 11900 14500 17500 21100 25200 29900 - -
30 - 10700 13100 16000 19400 23300 27700 32700 38400
40 - 9300 1160 0 14300 17400 21000 25000 29700 34900
50 - - 9900 12300 15100 18300 21900 26100 30800
60 - - - - 12500 15200 18400 22100 26300
68 - - - - - - - - -
3600 rpm
60
20 24500 29300 35200 42400 50800 60700 72100 - -
30 21800 26500 32200 39000 46900 56200 66900 79100 93100
40 - 24000 29300 35500 42800 51300 61100 72400 85200
50 - - 26200 31700 38200 45800 54500 64600 76200
60 - - - - 32900 39400 47000 55900 66100
68 - - - - - - 41000 49000 58200
6000 rpm
100
20 - 48200 58500 70800 85300 102100 121500 - -
30 - 43000 52900 64400 77900 93500 111400 131800 154900
40 - 38900 48100 58800 71200 85400 101800 120400 141400
50 - - 43400 53100 64200 77000 91700 108400 127300
60 - - - - 56400 67700 80600 95400 112200
68 - - - - - - - - -
To: Evaporating temperature in °C Superheat = 11.1 K Presented data are for models with motor voltage code H
Tc: Condensing temperature in °C Subcooling = 8.3 K
Qo: Cooling capacity in W
14 FRCC.PC.023.A8.02
Application Guidelines
