Danfoss VZH088-G single User Manual

Technical specications
Capacity at EN12900 rating conditions - High pressure ratio - VZH088AH - VZH117AH - VZH170AH
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088AH*
1500 rpm
25
20 - 5400 6600 8100 9800 11800 14000 - -
30 - 4800 6000 7400 9000 10800 12900 15300 17900
40 - 4200 5300 6600 8100 9800 11700 13800 16200
50 - - 4500 5700 7000 8500 10200 12100 14300
60 - - - - 5700 7000 8500 10100 11900
68 - - - - - - - - -
3600 rpm
60
20 11300 13800 16800 20300 24500 29300 34800 - -
30 9800 12200 15000 18300 22200 26700 31800 37600 44200
40 - 10700 13300 16300 19900 23900 28500 33800 39800
50 - - 11500 14200 17300 20900 25000 29700 35000
60 - - - - 14400 17500 21000 25000 29600
68 - - - - - - 17300 20800 24800
6000 rpm
100
20 - 22500 27400 33200 40000 48000 57100 - -
30 - 20200 24900 30400 36700 44100 52500 62100 73000
40 - 18100 22300 27300 33100 39800 47400 56200 66000
50 - - 19500 23900 29000 34900 41600 49300 58000
60 - - - - 24200 29100 34800 41300 48800
68 - - - - - - - - -
VZH117AH*
1500 rpm
25
20 - 7200 8900 10800 13100 15800 18800 - -
30 - 6400 8000 9900 12100 14500 17300 20500 24100
40 - 5600 7100 8900 10900 13100 15700 18600 21800
50 - - 6100 7700 9400 1150 0 13700 16300 19100
60 - - - - 7700 9400 11400 13500 16000
68 - - - - - - - - -
3600 rpm
60
20 15100 18500 22500 27300 32900 39300 46700 - -
30 13100 16400 20200 24600 29800 35800 42600 50400 59300
40 - 14400 17900 21900 26700 32100 38300 45400 53400
50 - - 15500 19100 23200 28000 33600 39900 47000
60 - - - - 19300 23400 28100 33600 39800
68 - - - - - - 23200 27900 33300
6000 rpm
100
20 - 30200 36800 44600 53700 64400 76600 - -
30 - 27200 33400 40700 49300 59200 70500 83400 98000
40 - 24200 30000 36700 44500 53400 63700 75400 88600
50 - - 26200 32100 38900 46800 55800 66100 77900
60 - - - - 32400 39000 46700 55400 65500
68 - - - - - - - - -
VZH170AH*
1500 rpm
25
20 - 11200 13600 16400 19800 23600 28100 - -
30 - 9900 12200 14900 18000 21600 25800 30500 35800
40 - 8500 10600 13100 16000 19200 23000 27300 32200
50 - - 8900 11000 13600 16400 19800 23600 27900
60 - - - - 10800 13200 16000 19200 22900
68 - - - - - - - - -
3600 rpm
60
20 22900 27500 33000 39700 47700 57000 67700 - -
30 20200 24600 29900 36200 43600 52300 62300 73800 86800
40 - 21900 26800 32500 39300 47100 56200 66600 78500
50 - - 23400 28500 34300 41200 49200 58400 68900
60 - - - - 28500 34200 40900 48700 57700
68 - - - - - - 33200 39800 47400
6000 rpm
100
20 - 45100 54800 66400 80100 95900 114200 - -
30 - 39900 49000 59800 72400 87000 103700 122800 144500
40 - 35600 44100 53900 65300 78500 93500 110800 130300
50 - - 38900 47700 57800 69400 82700 97800 115000
60 - - - - 48900 58800 70100 83100 97900
68 - - - - - - - - -
To: Evaporating temperature in °C Superheat = 10 K Presented data are for models with motor voltage code H
Tc: Condensing temperature in °C Subcooling = 0 K
Qo: Cooling capacity in W
13FRCC.PC.023.A8.02
