Technical specications
Capacity at EN12900 rating conditions - High pressure ratio - VZH088AJ - VZH117AJ - VZH170AJ
Models
rpm
rps
Te -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088AJ
1500
25
20 - - 5300 1.5 6600 1.57 8000 1.65 9700 1.71 11700 1.7 13900 1.58 - - - -
30 - - 4800 2.08 5900 2.05 7300 2.07 8900 2.11 10800 2.14 12800 2.11 15200 1.98 17800 1.72
40 - - 4200 2.97 5300 2.78 6600 2.71 8000 2.7 9700 2.72 11600 2.74 13700 2.7 16100 2.58
50 - - - - 4500 3.85 5700 3.63 7000 3.53 8500 3.5 10200 3.52 12000 3.54 14100 3.52
60 - - - - - - - - 5700 4.67 7000 4.55 8400 4.53 10000 4.55 1180 0 4.59
68 - - - - - - - - - - - - - - - - - -
3600
60
20 11200 4.27 13700 4.34 16700 4.41 20200 4.5 24300 4.61 29100 4.74 34600 4.88 - - - -
30 9700 5.14 12100 5.2 14900 5.28 18200 5.36 22000 5.45 26500 5.57 31500 5.7 37300 5.85 43800 6.03
40 - - 10600 6.33 13200 6.39 16200 6.45 19700 6.53 23700 6.62 28300 6.73 33600 6.86 39500 7.01
50 - - - - 11500 7.89 14100 7.93 17200 7.98 20700 8.05 24800 8.13 29500 8.22 34800 8.34
60 - - - - - - - - 14300 9.94 17300 9.97 20800 10.01 24800 10.07 29400 10.14
68 - - - - - - - - - - - - 17200 11.97 20600 11.99 24600 12.02
6000
100
20 - - 22300 7.79 27200 8.1 33000 8.46 39700 8.87 47600 9.34 56600 9.89 - - - -
30 - - 20100 9.21 24700 9.45 30100 9.73 36500 10.05 43800 10.43 52100 10.87 61700 11. 38 72500 11.98
40 - - 17900 11.05 22200 11.22 27100 11.42 32900 11.6 4 39500 11.92 47100 12.24 55700 12.62 65500 13.08
50 - - - - 19400 13.59 23700 13.7 28800 13.83 34600 13.99 41300 14.19 48900 14.44 57600 14.75
60 - - - - - - - - 24000 16.8 28900 16.84 34500 16.91 41000 17.02 48400 17.17
68 - - - - - - - - - - - - - - - - - -
VZH117A J
1500
25
20 - - 7200 1.97 8800 2.06 10800 2.17 13000 2.24 15700 2.23 18700 2.07 - - - -
30 - - 6400 2.73 8000 2.69 9800 2.72 12000 2.78 14400 2.81 17200 2.77 20400 2.61 23900 2.26
40 - - 5600 3.9 7100 3.66 8800 3.56 10800 3.54 13000 3.57 15600 3.59 18400 3.55 21600 3.39
50 - - - - 6000 5.06 7600 4.77 9400 4.63 1140 0 4.6 13600 4.62 16200 4.64 19000 4.62
60 - - - - - - - - 7600 6.13 9300 5.98 11300 5.95 13400 5.98 15900 6.02
68 - - - - - - - - - - - - - - - - - -
3600
60
20 15000 5.6 18400 5.69 22400 5.8 27100 5.92 32600 6.06 39000 6.22 46400 6.42 - - - -
30 13000 6.75 16200 6.83 20000 6.93 24400 7.04 29600 7.16 35500 7.31 42300 7.48 50100 7.69 58800 7.92
40 - - 14300 8.31 17700 8.39 21800 8.48 26500 8.58 31800 8.7 38000 8.84 45100 9.01 53000 9.21
50 - - - - 15400 10.36 18900 10.42 23100 10.49 27800 10.57 33300 10.67 39600 10.8 46700 10.95
60 - - - - - - - - 19200 13.06 23200 13.1 27900 13.15 33300 13.23 39500 13.32
68 - - - - - - - - - - - - 23000 15.72 27700 15.75 33000 15.79
6000
100
20 - - 30000 10.23 36500 10.64 44200 11.11 53300 11.65 63900 12.27 76000 12.99 - - - -
30 - - 27000 12.09 33200 12.41 40400 12.78 48900 13.2 58700 13.7 70000 14.28 82800 14.95 97300 15.73
40 - - 24100 14.51 29800 14.74 36400 14.99 44100 15.29 53000 15.65 63200 16.08 74800 16.58 88000 17.18
50 - - - - 26000 17.85 31900 17.99 38600 18.16 46400 18.37 55400 18.64 65700 18.97 77300 19.37
60 - - - - - - - - 32200 22.06 38700 22.11 46300 22.2 55000 22.35 65000 22.56
68 - - - - - - - - - - - - - - - - - -
VZH170AJ
1500
25
20 - - 11100 3.15 13500 3.13 16300 3.1 19600 3.04 23500 2.9 27900 2.65 - - - -
30 - - 9800 4.09 12100 4.03 14800 4.02 17900 4.02 21500 4 25600 3.92 30300 3.75 35500 3.45
40 - - 8400 5.38 10500 5.2 13000 5.12 15800 5.1 19100 5.11 22800 5.12 27100 5.09 31900 4.98
50 - - - - 8800 6.85 11000 6.61 13500
6.49 16300 6.45 19600 6.46 23400 6.48 27700 6.48
60 - - - - - - - - 10700 8.39 13100 8.22 15900 8.15 19100 8.13 22800 8.15
68 - - - - - - - - - - - - - - - - - -
3600
60
20 22700 7.59 27200 7.76 32800 7.95 39400 8.12 47300 8.26 56500 8.34 67200 8.33 - - - -
30 20000 9.55 24400 9.64 29700 9.78 35900 9.95 43300 10.12 51900 10.26 61800 10.36 73200 10.38 86200 10.3
40 - - 21800 12.07 26600 12.12 32300 12.22 39000 12.37 46800 12.52 55800 12.66 66100 12.76 77900 12.81
50 - - - - 23300 15.09 28300 15.07 34100 15.13 40900 15.24 48800 15.37 57900 15.5 68400 15.61
60 - - - - - - - - 28300 18.56 34000 18.56 40600 18.63 48300 18.73 57300 18.84
68 - - - - - - - - - - - - 33000 21.72 39500 21.75 47100 21.83
6000
100
20 - - 44800 13.52 54400 14.12 65900 14.78 79500 15.55 95200 16.48 113300 17.61 - - - -
30 - - 39600 16.57 48700 17.14 59400 17.7 71900 18.29 86300 18.95 103000 19.74 121900 20.71 143400 21.89
40 - - 35300 20.18 43700 20.81 53500 21.35 64800 21.83 77900 22.3 92800 22.83 109900 23.44 129300 24.2
50 - - - - 38600 25.3 47300 25.88 57300 26.33 68800 26.7 82000 27.03 97100 27. 38 114200 27.79
60 - - - - - - - - 48500 31.97 58300 32.3 69600 32.52 82500 32.67 97200 32.81
68 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 10 K Presented data are for models with motor voltage code J
Tc: Condensing temperature in °C Subcooling = 0 K
Qo: Cooling capacity in W Pe: Power input in kW
9FRCC.PC.023.A8.02
Application Guidelines
