Ordering information and packaging
Compressor model Pressure ratio Equipment version Technical Name
X=motor code
G
380-480V/3ph/
50&60Hz
J
200-240V/3ph/
50&60Hz
H
525-600V/3ph/
50&60Hz
VZH088
High Single VZH088AXANA 120G0010 120G0012 120G0047
Low Single VZH088BXANA 120 G0011 120G0013 120G0049
High Manifold VZH088AXBNA 120G0022 120G0024 120G0048
Low Manifold VZH088BXBNA 120G0023 120G0025 120G0050
VZH117
High Single VZH117AXANA 120G0014 120G0016 120G0051
Low Single VZH117BXANA 120G0015 120G0017 120G0053
High Manifold VZH117AXBNA 120G0026 120G0028 120G0052
Low Manifold VZH117BXBNA 120G0027 120G0029 120G0054
VZH170
High Single VZH170AXANB 120G0018 120G0020 120G0055
Low Single VZH170BXANB 120G0019 120G0021 120G0057
High Manifold VZH170AXBNB 120G0030 120G0032 120G0056
Low Manifold VZH170BXBNB 120G0031 120G0033 120G0058
The tables on the following pages give code
numbers for ordering purposes for the VZH
compressor and CDS303 frequency converter kit
packed and shipped separately.
VZH scroll compressors can be ordered in single
packs or industrial packs while VZH frequency
converters can only be ordered in single pack.
Please use the code numbers from below tables
for ordering. A coil for injection valve must be
ordered separately.
Kit ordering and shipping
Compressor single pack
Compressor industrial pack
Packaging
Frequency converter single
pack
Compressors single pack
Ordering information
Compressor model
Height
(mm)
Width
(mm)
Depth
(mm)
Weight
(kg)
VZH088 718 565 470 70
VZH117 718 565 470 76
VZH170 765 515 450 112
Compressor model Nbr*
Length
(mm)
Width
(mm)
Height
(mm)
Gross Weight
(kg)
Static stacking
pallets
VZH088 8 1150 950 680 494 2
VZH117 8 1150 950 750 544 2
VZH170 4 1150 965 768 647 2
Drive
supply
voltage
Drive
power
(kW)
IP20 IP55
Height
(mm)
Width
(mm)
Depth
(mm)
Weight
(kg)
Height
(mm)
Width
(mm)
Depth
(mm)
Weight
(kg)
T2:
Code J
15 346 810 320 24 430 805 405 46
18 - 22 437 805 405 36 437 805 405 46
T4:
Code G
15 349 500 330 13 346 810 320 24
18 - 22 346 810 320 24 346 810 320 28
T6:
code H
18.5-30 346 810 320 24 - - - -
Depth
Height
Width
CD303 packaging
63FRCC.PC.023.A8.02
Application Guidelines
