Danfoss VZH088-G single User Manual

Dimensions
VZH170-J manifolded versionVZH170-J single version
HM 8 bolt
Lock washer
Flat washer
Steel mounting sleeve
Rubber grommet
Nut
28 mm
Compressor
base plate
Ø 50.5 mm hole
Ø 63.5 mm knockout
Ø 22.5 mm knockout
Sump heater
Grommet
All dimensions in mm
Electrical box
Ø266
Discharge
1"1/8
Ø257
4 holes Ø19
Ø318
277
172
301.5
76.6
345
279.4
304.8
371
30°
60°
60° 2x
219
192
481
277
309
353
81.6
151.5
531
617
92.5
659
max.
Suction
1"5/8
4 holes Ø19
oil equalisation Ø38
2.25" - 12 UN - 2A
345
279.4
192
481
277
60°
219
304.8
371
352
30°
60° 2x
Ø266
Ø257
Ø318
76.6
301.5
81.6
151.5
531
617
172
277
659
max.
Suction
1"5/5
92.5
Discharge
1"1/8
26 FRCC.PC.023.A8.02
Application Guidelines

Danfoss VZH088-G single Specifications

General

Brand	Danfoss
Model	VZH088-G single
Category	Air Compressor
Language	English
