Dimensions
VZH088-G/H single
version
VZH088-G/H manifolded version
15 mm
HM 8 bolt
Lock washer
Flat washer
Steel mounting
sleeve
Rubber grommet
Nut
Ø 33 mm hole
Grommet
All dimensions in mm
Electrical box
Ø224
Ø220.8
Ø243
469.7
max.
93
148
78.7
179.9
230
230
190.5
190.5
180.7
154
158
4 holes
Ø19.05
30°
30°
60°
15.1 with
compression
219.5
436.1
Discharge
7/8"
Suction
1"1/8
Ø224
Ø220.8
Ø243
219.5
436.1
4 holes
Ø19.05
oil equalisation
Ø32 - 1.75" -
12UN - 2A
230
30°
30°
60°
230
190.5
180.7
154
158
190.5
93
59.7
78.7
Discharge
7/8"
Suction
1"1/8
148
15.1 with
compression
469.7
max.
21FRCC.PC.023.A8.02
