Page #20 background imageLoading...
Page #20 background image
Technical specications
Capacity at ARI rating conditions - Low pressure ratio - VZH088BH - VZH117BH- VZH170BH
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088BH*
1500 rpm
25
20 - 6500 7900 9400 11200 13300 15700 - -
30 - 5600 6900 8300 10100 12000 14200 16700 19600
40 - 4700 5900 7300 8900 10700 12700 15100 17700
50 - - - 6200 7600 9300 11200 13400 15800
60 - - - - - 7900 9600 11600 13900
63 - - - - - - - - -
3600 rpm
60
20 1190 0 14600 17800 21700 26200 31400 37400 - -
30 10500 13100 16200 19800 24100 28900 34400 40700 47700
40 - 11700 14600 18000 21900 26300 31400 37100 43500
50 - - - 15900 19500 23500 28100 33200 39100
60 - - - - - 20200 24300 29000 34200
63 - - - - - - 23200 27600 32700
6000 rpm
100
20 - 23900 28900 34900 42000 50200 59600 - -
30 - 22000 26900 32700 39500 47300 56200 66400 77900
40 - 19800 24500 29900 36200 43400 51700 61100 71800
50 - - - 26400 32000 38500 45900 54400 64100
60 - - - - - 32600 39100 46500 55100
63 - - - - - - - - -
VZH117BH*
1500 rpm
25
20 - 8700 10500 12700 15100 17900 21100 - -
30 - 7500 9200 11200 13500 16100 19100 22500 26300
40 - 6300 7900 9800 11900 14300 17100 20200 23800
50 - - - 8300 10200 12500 15000 18000 21300
60 - - - - - 10600 12900 15600 18700
63 - - - - - - - - -
3600 rpm
60
20 15900 19600 23900 29100 35200 42200 50200 - -
30 14100 17600 21800 26600 32300 38800 46200 54600 64000
40 - 15700 19600 24200 29400 35300 42100 49800 58500
50 - - - 21400 26100 31500 37700 44600 52400
60 - - - - - 27200 32700 38900 45900
63 - - - - - - 31100 37100 43900
6000 rpm
100
20 - 32000 38800 46900 56300 67300 80000 - -
30 - 29500 36100 43900 53000 63500 75500 89200 104600
40 - 26600 32900 40100 48600 58300 69400 82000 96300
50 - - - 35400 43000 51700 61600 73100 86000
60 - - - - - 43800 52500 62500 73900
63 - - - - - - - - -
VZH170BH*
1500 rpm
25
20 - 12400 14900 17900 21400 25400 30000 - -
30 - 10800 13300 16100 19400 23200 27600 32500 38100
40 - 9300 1160 0 14300 17300 20900 24900 29600 34800
50 - - - 12200 15100 18300 22000 26300 31200
60 - - - - - 15500 18900 22800 27300
63 - - - - - - - - -
3600 rpm
60
20 22900 28200 34600 42200 51100 61400 73300 - -
30 20500 25600 31600 38700 47000 56600 67700 80400 94800
40 - 22900 28400 34900 42500 51300 61500 73100 86400
50 - - - 30900 37600 45500 54700 65200 77200
60 - - - - - 39300 47300 56600 67400
63 - - - - - - 45100 54100 64500
6000 rpm
100
20 - 47100 57600 70000 84500 101400 120800 - -
30 - 42800 52900 64700 78500 94400 112700 133500 157200
40 - 38300 47700 58700 71500 86300 103200 122600 144700
50 - - - 52000 63500 76900 92400 110100 130400
60 - - - - - 66600 80400 96400 11470 0
63 - - - - - - - - -
To: Evaporating temperature in °C Superheat = 11.1 K Presented data are for models with motor voltage code H
Tc: Condensing temperature in °C Subcooling = 8.3 K
Qo: Cooling capacity in W
20 FRCC.PC.023.A8.02
