Technical specications
Capacity at EN12900 rating conditions - Low pressure ratio - VZH088BH - VZH117BH - VZH170BH
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088BH*
1500 rpm
25
20 - 6100 7400 8800 10600 12500 14700 - -
30 - 5200 6400 7800 9300 11200 13200 15600 18300
40 - 4300 5400 6700 8100 9800 11700 13900 16300
50 - - - 5500 6900 8400 10100 12100 14300
60 - - - - - 6800 8400 10100 12200
63 - - - - - - - - -
3600 rpm
60
20 11100 13600 16700 20400 24600 29500 35100 - -
30 9700 12200 15000 18400 22400 26900 32000 37900 44500
40 - 10700 13400 16500 20100 24200 28800 34100 40100
50 - - - 14300 17500 21100 25300 30000 35300
60 - - - - - 17600 21200 25200 29800
63 - - - - - - 19800 23700 28100
6000 rpm
100
20 - 22300 27100 32700 39400 47100 56000 - -
30 - 20400 25000 30400 36700 44000 52400 61900 72700
40 - 18100 22400 27400 33200 39900 47500 56200 66100
50 - - - 23700 28800 34700 41400 49100 57900
60 - - - - - 28300 34000 40600 48100
63 - - - - - - - - -
VZH117BH*
1500 rpm
25
20 - 8200 9900 11900 14200 16800 19800 - -
30 - 6900 8500 10400 12500 15000 17800 20900 24500
40 - 5700 7200 8900 10900 13200 15700 18600 21900
50 - - - 7400 9200 11200 13600 16200 19200
60 - - - - - 9200 1120 0 13600 16300
63 - - - - - - - - -
3600 rpm
60
20 14900 18300 22400 27300 33000 39600 47200 - -
30 13100 16300 20200 24700 30000 36100 43000 50900 59700
40 - 14400 18000 22100 26900 32400 38700 45800 53800
50 - - - 19200 23500 28400 34000 40300 47400
60 - - - - - 23600 28400 33900 40100
63 - - - - - - 26500 31800 37700
6000 rpm
100
20 - 30000 36400 43900 52900 63200 75200 - -
30 - 27400 33500 40800 49300 59100 70300 83100 97500
40 - 24400 30100 36800 44500 53500 63800 75500 88700
50 - - - 31800 38600 46500 55600 66000 77700
60 - - - - - 38000 45600 54400 64500
63 - - - - - - - - -
VZH170BH*
1500 rpm
25
20 - 11600 14000 16800 20100 23800 28200 - -
30 - 10000 12300 15000 18100 21600 25700 30300 35500
40 - 8500 10600 13100 15900 19200 22900 27200 32000
50 - - - 11000 13500 16500 19900 23800 28200
60 - - - - - 13500 16500 19900 23800
63 - - - - - - - - -
3600 rpm
60
20 21400 26400 32400 39600 47900 57700 68900 - -
30 19000 23700 29300 35900 43700 52700 63000 74900 88400
40 - 20900 26000 32000 39000 47100 56500 67300 79600
50 - - - 27700 33800 41000 49300 58800 69800
60 - - - - - 34100 41100 49400 58800
63 - - - - - - 38500 46300 55300
6000 rpm
100
20 - 44100 54000 65700 79300 95200 113500 - -
30 - 39700 49100 60100 72900 87800 104900 124500 146600
40 - 35000 43700 53800 65600 79200 94900 112900 133300
50 - - - 46700 57100 69300 83300 99400 11780 0
60 - - - - - 57800 69900 84000 100100
63 - - - - - - - - -
To: Evaporating temperature in °C Superheat = 10 K Presented data are for models with motor voltage code H
Tc: Condensing temperature in °C Subcooling = 0 K
Qo: Cooling capacity in W
19FRCC.PC.023.A8.02
