Danfoss VZH088-G single User Manual

Technical specications
Capacity at ARI rating conditions - Low pressure ratio - VZH088BG - VZH117BG - VZH170BG
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BG
1500 rpm
25
20 - - 6500 1.8 7900 1.7 9400 1.61 11200 1.54 13300 1.49 15700 1.46 - - - -
30 - - 5600 2.34 6900 2.26 8300 2.18 10100 2.1 12000 2.03 14200 1.96 16700 1.91 19600 1.88
40 - - 4700 2.93 5900 2.89 7300 2.83 8900 2.77 10700 2.7 12700 2.63 15100 2.56 17700 2.49
50 - - - - - - 6200 3.65 7600 3.62 9300 3.58 11200 3.52 13400 3.45 15800 3.37
60 - - - - - - - - - - 7900 4.73 9600 4.7 11600 4.65 13900 4.59
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 11900 4.45 14600 4.42 17800 4.34 21700 4.23 26200 4.13 31400 4.07 37400 4.07 - - - -
30 10500 5.48 13100 5.54 16200 5.5 19800 5.41 24100 5.28 28900 5.16 34400 5.06 40700 5.03 47700 5.09
40 - - 11700 6.8 14600 6.86 18000 6.82 21900 6.72 26300 6.58 31400 6.44 37100 6.32 43500 6.26
50 - - - - - - 15900 8.5 19500 8.47 23500 8.37 28100 8.23 33200 8.07 39100 7.94
60 - - - - - - - - - - 20200 10.56 24300 10.46 29000 10.32 34200 10.17
63 - - - - - - - - - - - - 23200 11.22 27600 11.1 32700 10.94
6000 rpm
100
20 - - 23900 7.6 28900 7.6 34900 7.55 42000 7. 54 50200 7.62 59600 7. 86 - - - -
30 - - 22000 9.67 26900 9.74 32700 9.69 39500 9.6 47300 9.52 56200 9.52 66400 9.67 77900 10.03
40 - - 19800 11.78 24500 12.02 29900 12.06 36200 11.98 43400 11.8 4 51700 11.69 61100 11.62 71800 11.69
50 - - - - - - 26400 14.58 32000 14.61 38500 14.49 45900 14.3 54400 14.1 64100 13.96
60 - - - - - - - - - - 32600 17.4 39100 17.26 46500 17.03 55100 16.78
63 - - - - - - - - - - - - - - - - - -
VZH117BG
1500 rpm
25
20 - - 8700 2.36 10500 2.23 12700 2.12 15100 2.02 17900 1.95 21100 1.91 - - - -
30 - - 7500 3.07 9200 2.96 1120 0 2.86 13500 2.76 16100 2.66 19100 2.58 22500 2.51 26300 2.47
40 - - 6300 3.84 7900 3.79 9800 3.72 11900 3.64 14300 3.55 17100 3.45 20200 3.36 23800 3.27
50 - - - - - - 8300 4.8 10200 4.76 12500 4.7 15000 4.62 18000 4.53 21300 4.43
60 - - - - - - - - - - 10600 6.21 12900 6.18 15600 6.11 18700 6.02
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 15900 5.84 19600 5.8 23900 5.7 29100 5.56 35200 5.43 42200 5.35 50200 5.35 - - - -
30 14100 7.2 17600 7. 27 21800 7.22 26600 7.1 32300 6.94 38800 6.77 46200 6.65 54600 6.61 64000 6.69
40 - - 15700 8.93 19600 9 24200 8.95 29400 8.82 35300 8.64 42100 8.46 49800 8.3 58500 8.22
50 - - - - - - 21400 11.17 26100 11.12 31500 10.99 37700 10.8 44600 10.61 52400 10.43
60 - - - - - - - - - - 27200 13.86 32700 13.74 38900 13.56 45900 13.35
63 - - - - - - - - - - - - 31100 14.74 37100 14.57 43900 14.37
6000 rpm
100
20 - - 32000 9.98 38800 9.98 46900 9.92 56300 9.9 67300 10.01 80000 10.32 - - - -
30 - - 29500 12.7 36100 12.79 43900 12.73 53000 12.61 63500 12.5 75500 12.5 89200 12.7 104600 13.17
40 - - 26600 15.47 32900 15.78 40100 15.84 48600 15.74 58300 15.54 69400 15.36 82000 15.26 96300 15.35
50 - - - - - - 35400 19.15 43000 19.18 51700 19.03 61600 18.78 73100 18.52 86000 18.34
60 - - - - - - - - - - 43800 22.85 52500 22.66 62500 22.37 73900 22.04
63 - - - - - - - - - - - - - - - - - -
VZH170BG
1500 rpm
25
20 - - 12400 3.17 14900 3.04 17900 2.91 21400 2.76 25400 2.6 30000 2.41 - - - -
30 - - 10800 4.3 13300 4.16 16100 4.03 19400 3.9 23200 3.76 27600 3.6 32500 3.42 38100 3.2
40 - - 9300 5.55 11600 5.4 14300 5.27 17300 5.15 20900 5.04 24900 4.92 29600 4.78 34800 4.63
50 - - - - - - 12200 6.78 15100
6.68 18300 6.59 22000 6.5 26300 6.42 31200 6.32
60 - - - - - - - - - - 15500 8.57 18900 8.52 22800 8.48 27300 8.43
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 22900 8.35 28200 8.2 34600 8.03 42200 7.84 51100 7.61 61400 7.32 73300 6.96 - - - -
30 20500 10.39 25600 10.26 31600 10.14 38700 10 47000 9.85 56600 9.65 67700 9.39 80400 9.06 94800 8.64
40 - - 22900 12.73 28400 12.62 34900 12.52 42500 12.42 51300 12.28 61500 12.11 73100 11.87 86400 11. 57
50 - - - - - - 30900 15.65 37600 15.57 45500 15.48 54700 15.36 65200 15.2 77200 14.99
60 - - - - - - - - - - 39300 19.5 47300 19.41 56600 19.31 67400 19.16
63 - - - - - - - - - - - - 45100 20.82 54100 20.73 64500 20.59
6000 rpm
100
20 - - 47100 14.69 57600 14.8 70000 14.75 84500 14.48 101400 13.95 120800 13.1 - - - -
30 - - 42800 17.7 52900 17.95 64700 18.1 78500 18.11 94400 17.92 112700 17.49 133500 16.75 157200 15.67
40 - - 38300 21.48 47700 21.74 58700 21.98 71500 22.15 86300 22.19 103200 22.05 122600 21.68 144700 21.03
50 - - - - - - 52000 26.84 63500 27.04 76900 27.18 92400 27.22 110100 27.09 130400 26.76
60 - - - - - - - - - - 66600 33.36 80400 33.45 96400 33.45 114700 33.31
63 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 11.1 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °C Subcooling = 8.3 K
Qo: Cooling capacity in W Pe: Power input in kW
18 FRCC.PC.023.A8.02
Application Guidelines
