Technical specications
Capacity at EN12900 rating conditions - Low pressure ratio - VZH088BG - VZH117BG - VZH170BG
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BG
1500 rpm
25
20 - - 6100 1.8 7400 1.7 8800 1.61 10600 1.54 12500 1.49 14700 1.46 - - - -
30 - - 5200 2.34 6400 2.26 7800 2.18 9300 2.1 1120 0 2.03 13200 1.96 15600 1.91 18300 1.88
40 - - 4300 2.93 5400 2.89 6700 2.83 8100 2.77 9800 2.7 11700 2.63 13900 2.56 16300 2.49
50 - - - - - - 5500 3.65 6900 3.62 8400 3.58 10100 3.52 12100 3.45 14300 3.37
60 - - - - - - - - - - 6800 4.73 8400 4.7 10100 4.65 12200 4.59
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 11100 4.45 13600 4.42 16700 4.34 20400 4.23 24600 4.13 29500 4.07 35100 4.07 - - - -
30 9700 5.48 12200 5.54 15000 5.5 18400 5.41 22400 5.28 26900 5.16 32000 5.06 37900 5.03 44500 5.09
40 - - 10700 6.8 13400 6.86 16500 6.82 20100 6.72 24200 6.58 28800 6.44 34100 6.32 40100 6.26
50 - - - - - - 14300 8.5 17500 8.47 2110 0 8.37 25300 8.23 30000 8.07 35300 7.94
60 - - - - - - - - - - 17600 10.56 21200 10.46 25200 10.32 29800 10.17
63 - - - - - - - - - - - - 19800 11.22 23700 11.1 28100 10.94
6000 rpm
100
20 - - 22300 7.6 27100 7.6 32700 7.55 39400 7. 54 47100 7.62 56000 7.86 - - - -
30 - - 20400 9.67 25000 9.74 30400 9.69 36700 9.6 44000 9.52 52400 9.52 61900 9.67 72700 10.03
40 - - 18100 11.78 22400 12.02 27400 12.06 33200 11.98 39900 11.84 47500 11.69 56200 11.62 66100 11.69
50 - - - - - - 23700 14.58 28800 14.61 34700 14.49 41400 14.3 49100 14.1 57900 13.96
60 - - - - - - - - - - 28300 17.4 34000 17.26 40600 17.03 48100 16.78
63 - - - - - - - - - - - - - - - - - -
VZH117BG
1500 rpm
25
20 - - 8200 2.36 9900 2.23 11900 2.12 14200 2.02 16800 1.95 19800 1.91 - - - -
30 - - 6900 3.07 8500 2.96 10400 2.86 12500 2.76 15000 2.66 17800 2.58 20900 2.51 24500 2.47
40 - - 5700 3.84 7200 3.79 8900 3.72 10900 3.64 13200 3.55 15700 3.45 18600 3.36 21900 3.27
50 - - - - - - 7400 4.8 9200 4.76 1120 0 4.7 13600 4.62 16200 4.53 19200 4.43
60 - - - - - - - - - - 9200 6.21 11200 6.18 13600 6.11 16300 6.02
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 14900 5.84 18300 5.8 22400 5.7 27300 5.56 33000 5.43 39600 5.35 47200 5.35 - - - -
30 13100 7.2 16300 7.27 20200 7.22 24700 7.1 30000 6.94 36100 6.77 43000 6.65 50900 6.61 59700 6.69
40 - - 14400 8.93 18000 9 22100 8.95 26900 8.82 32400 8.64 38700 8.46 45800 8.3 53800 8.22
50 - - - - - - 19200 11.17 23500 11.12 28400 10.99 34000 10.8 40300 10.61 47400 10.43
60 - - - - - - - - - - 23600 13.86 28400 13.74 33900 13.56 40100 13.35
63 - - - - - - - - - - - - 26500 14.74 31800 14.57 37700 14.37
6000 rpm
100
20 - - 30000 9.98 36400 9.98 43900 9.92 52900 9.9 63200 10.01 75200 10.32 - - - -
30 - - 27400 12.7 33500 12.79 40800 12.73 49300 12.61 59100 12.5 70300 12.5 83100 12.7 97500 13.17
40 - - 24400 15.47 30100 15.78 36800 15.84 44500 15.74 53500 15.54 63800 15.36 75500 15.26 88700 15.35
50 - - - - - - 31800 19.15 38600 19.18 46500 19.03 55600 18.78 66000 18.52 77700 18.34
60 - - - - - - - - - - 38000 22.85 45600 22.66 54400 22.37 64500 22.04
63 - - - - - - - - - - - - - - - - - -
VZH170BG
1500 rpm
25
20 - - 11600 3.17 14000 3.04 16800 2.91 20100 2.76 23800 2.6 28200 2.41 - - - -
30 - - 10000 4.3 12300 4.16 15000 4.03 18100 3.9 21600 3.76 25700 3.6 30300 3.42 35500 3.2
40 - - 8500 5.55 10600 5.4 13100 5.27 15900 5.15 19200 5.04 22900 4.92 27200 4.78 32000 4.63
50 - - - - - - 11000 6.78 13500
6.68 16500 6.59 19900 6.5 23800 6.42 28200 6.32
60 - - - - - - - - - - 13500 8.57 16500 8.52 19900 8.48 23800 8.43
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 21400 8.35 26400 8.2 32400 8.03 39600 7.84 47900 7.61 57700 7. 32 68900 6.96 - - - -
30 19000 10.39 23700 10.26 29300 10.14 35900 10 43700 9.85 52700 9.65 63000 9.39 74900 9.06 88400 8.64
40 - - 20900 12.73 26000 12.62 32000 12.52 39000 12.42 47100 12.28 56500 12.11 67300 11.87 79600 11.57
50 - - - - - - 27700 15.65 33800 15.57 41000 15.48 49300 15.36 58800 15.2 69800 14.99
60 - - - - - - - - - - 34100 19.5 41100 19.41 49400 19.31 58800 19.16
63 - - - - - - - - - - - - 38500 20.82 46300 20.73 55300 20.59
6000 rpm
100
20 - - 44100 14.69 54000 14.8 65700 14.75 79300 14.48 95200 13.95 11350 0 13.1 - - - -
30 - - 39700 17.7 49100 17.95 60100 18.1 72900 18.11 87800 17.92 104900 17.49 124500 16.75 146600 15.67
40 - - 35000 21.48 43700 21.74 53800 21.98 65600 22.15 79200 22.19 94900 22.05 112900 21.68 133300 21.03
50 - - - - - - 46700 26.84 57100 27.04 69300 27.18 83300 27.22 99400 27.09 117800 26.76
60 - - - - - - - - - - 57800 33.36 69900 33.45 84000 33.45 100100 33.31
63 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 10 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °C Subcooling = 0 K
Qo: Cooling capacity in W Pe: Power input in kW
17FRCC.PC.023.A8.02
