Danfoss VZH088-G single User Manual

Compressor
model
Frequency converter
Model & power IP class RFI class Coating
Code n° for
ordering
VZH088-J
CDS303
15.0kW
IP20
H3 No 134G3474
H2
No 134F9361
Yes 134X1964
IP55
H3 No 134G4001
H2 No 134G4002
VZH117-J
CDS303
18.5kW
IP20
H3 No 134G3585
H2
No 134F9363
Yes 134X1965
IP55
H3 No 134G4003
H2 No 134G4004
VZH170-J
CDS303
22.0kW
IP20
H3 No 134G3586
H2
No 134F9365
Yes 134X1966
IP55
H3 No 134G4005
H2 No 134G4006
Accessories
Valves, adapters, connectors & gaskets for use on suction and discharge connections
Crankcase heaters & thermostats
Crankcase heaters
Type Code n° Description Application Packaging Pack size
120Z0388 Surface sump heater, 80 W, 24 V, CE, UL
VZH088-117
Multipack 8
120Z0389 Surface sump heater, 80 W, 230 V, CE, UL Multipack 8
120Z0390 Surface sump heater, 80 W, 400 V, CE, UL Multipack 8
120Z0391 Surface sump heater, 80 W, 460 V,CE, UL Multipack 8
120Z0402 Surface sump heater, 80 W, 575 V, CE, UL Multipack 8
120Z0360 Surface sump heater + bottom insulation, 56 W, 24 V, CE, UL
VZH170
Multipack 6
120Z0376 Surface sump heater + bottom insulation, 56 W, 230 V, CE, UL Multipack 6
120Z0377 Surface sump heater + bottom insulation, 56 W, 400 V, CE, UL Multipack 6
120Z0378 Surface sump heater + bottom insulation, 56 W, 460 V, CE, UL Multipack 6
120Z0379 Surface sump heater + bottom insulation, 56 W, 575 V, CE, UL Multipack 6
Surface sump heaters
Type Code n° Description Application Packaging Pack size
120Z0157 Discharge temperature sensor / converter kit VZH all models Single pack 1
120Z0158 Discharge temperature sensor VZH all models Single pack 1
120Z0159 Discharge temperature converter VZH all models Single pack 1
7750009 Discharge thermostat kit VZH all models Multipack 10
Discharge thermostats and sensors
Lubricant, acoustic hoods and spare parts
Type Code n° Description Application Packaging Pack size
120Z0509 VZH088-G acoustic hood VZH088-G/H Single pack 1
120Z0510 VZH088-J acoustic hood VZH088-J Single pack 1
120Z0511 VZH088-G manifolding acoustic hood VZH088-G/H manifolding Single pack 1
120Z0512 VZH088-J manifolding acoustic hood VZH088-J manifolding Single pack 1
120Z0513 VZH117-G acoustic hood VZH117-G/H Single pack 1
120Z0514 VZH117-J acoustic hood VZH117-J Single pack 1
120Z0515 VZH117-G manifolding acoustic hood VZH117-G/H manifolding Single pack 1
120Z0516 VZH117-J manifolding acoustic hood VZH117-J manifolding Single pack 1
120Z0517 VZH170-G acoustic hood VZH170-G/H Single pack 1
120Z0519 VZH170-J acoustic hood VZH170-J Single pack 1
120Z0518 VZH170-G manifolding acoustic hood VZH170-G/H manifolding Single pack 1
120Z0520 VZH170-J manifolding acoustic hood VZH170-J manifolding Single pack 1
Acoustic hoods
Type Code n° Description Application Packaging Pack size
120Z0125
Solder sleeve adapter set (1"3/4 Rotolock, 1"1/8 ODF),
(1"1/4 Rotolock, 7/8" ODF)
VZH088 Multipack 8
120Z0405
Solder sleeve adapter set (1"3/4 Rotolock, 1"3/8 ODF),
(1"1/4 Rotolock, 7/8" ODF)
VZH117 Multipack 8
7765028
Solder sleeve adapter set, (2"1/4 Rotolock, 1"5/8 ODF),
(1"3/4 Rotolock, 1"1/8 ODF)
VZH170 Multipack 6
Solder sleeve adapter sets
Type Code n° Description Application Packaging Pack size
7773109 Belt type crankcase heater, 65 W, 110 V, CE mark, UL
VZH088-117
Multipack 6
7973001 Belt type crankcase heater, 65 W, 110 V, CE mark, UL Industry pack 50
7773107 Belt type crankcase heater, 65 W, 230 V, CE mark, UL Multipack 6
120Z0038 Belt type crankcase heater, 65 W, 230 V, CE mark, UL Multipack 8
7973002 Belt type crankcase heater, 65 W, 230 V, CE mark, UL Industry pack 50
7773117 Belt type crankcase heater, 65 W, 400 V, CE mark, UL Multipack 6
120Z0039 Belt type crankcase heater, 65 W, 400 V, CE mark, UL Multipack 8
120Z0466 Belt type crankcase heater, 65 W, 460 V, CE mark, UL Multipack 6
120Z0467 Belt type crankcase heater, 65 W, 575 V, CE mark, UL Multipack 6
7773110 Belt type crankcase heater, 75 W, 110 V, CE mark, UL
VZH170
Multipack 6
7773108 Belt type crankcase heater, 75 W, 230 V, CE mark, UL Multipack 6
7773118 Belt type crankcase heater, 75 W, 400 V, CE mark, UL Multipack 6
67FRCC.PC.023.A8.02
Application Guidelines
