Danfoss VZH088-G single - VZH117-G;H Single Version; VZH117-G;H Manifolded Version

Dimensions
VZH117-G/H single version VZH117-G/H manifolded version
15 mm
HM 8 bolt
Lock washer
Flat washer
Steel mounting
sleeve
Rubber grommet
Nut
Ø 33 mm hole
Grommet
All dimensions in mm
Electrical box
93
195
527.2
max.
Ø220.8
4 holes
Ø19.05
493.5
262.5
85.6
179.9
230
230
180.7
154
173
30°
30°
60°
190.5
190.5
14.4 with
compression
Ø243
Suction
1"3/8
Ø224
Discharge
7/8"
Ø224
Ø220.8
Ø243
4 hole
Ø19.05
Ø32 oil equalisation
1.75" - 12 UN - 2A
493.5
262.5
85.6
57.6
93
195
181.9
230
230
190.5
142.7
180.7
154
173
30°
30°
60°
190.5
14.4 with
compression
527.2
max.
Discharge 7/8"
Suction
1"3/8
23FRCC.PC.023.A8.02
Application Guidelines
