Technical specications
Capacity at ARI rating conditions - Low pressure ratio - VZH088BJ - VZH117BJ - VZH170BJ
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BJ
1500 rpm
25
20 - - 6400 1.83 7800 1.73 9400 1.64 1120 0 1.57 13200 1.52 15600 1.48 - - - -
30 - - 5500 2.38 6800 2.3 8300 2.22 10000 2.14 11900 2.06 14100 2 16600 1.95 19400 1.92
40 - - 4600 2.98 5800 2.94 7200 2.88 8800 2.82 10600 2.75 12600 2.68 15000 2.6 17600 2.54
50 - - - - - - 6100 3.72 7600 3.69 9200 3.64 11100 3.58 13300 3.51 15700 3.43
60 - - - - - - - - - - 7800 4.81 9600 4.79 11600 4.74 13800 4.67
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 11800 4.53 14500 4.5 17700 4.42 21500 4.31 26000 4.21 31200 4.14 37100 4.15 - - - -
30 10400 5.58 13000 5.64 16100 5.6 19700 5.5 23900 5.38 28700 5.25 34200 5.16 40400 5.12 47400 5.18
40 - - 11600 6.92 14500 6.98 17900 6.94 21700 6.84 26100 6.7 31100 6.55 36800 6.44 43200 6.38
50 - - - - - - 15800 8.66 19300 8.62 23300 8.52 27800 8.37 33000 8.22 38800 8.09
60 - - - - - - - - - - 20100 10.75 24100 10.65 28700 10.51 33900 10.35
63 - - - - - - - - - - - - 23000 11.43 27400 11.3 32500 11.14
6000 rpm
100
20 - - 23700 7.74 28700 7.73 34600 7.69 41700 7.68 49800 7.76 59100 8 - - - -
30 - - 21800 9.84 26700 9.92 32500 9.87 39200 9.77 46900 9.69 55800 9.69 65900 9.84 77300 10.21
40 - - 19700 11.99 24300 12.23 29700 12.28 35900 12.2 43100 12.05 51300 11.9 60700 11. 83 71200 11.9
50 - - - - - - 26200 14.84 31800 14.87 38200 14.75 45600 14.56 54000 14.36 63600 14.22
60
- -
- - - - - - - - 32400 17.71 38800 17. 57 46200 17.34 54700 17.08
63
- -
- - - - - - - - - - - - - - - -
VZH117BJ
1500 rpm
25
20 - - 8600 2.4 10500 2.27 12600 2.16 15000 2.06 17700 1.99 20900 1.95 - - - -
30 - - 7400 3.12 9100 3.02 1110 0 2.91 13400 2.81 16000 2.71 18900 2.62 22300 2.56 26100 2.52
40 - - 6200 3.91 7800 3.86 9700 3.79 11800 3.7 14200 3.61 17000 3.51 20100 3.42 23600 3.33
50 - - - - - - 8200 4.88 10200 4.85 12400 4.79 14900 4.71 17800 4.61 2110 0 4.51
60 - - - - - - - - - - 10500 6.32 12800 6.29 15500 6.22 18600 6.13
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 15800 5.95 19400 5.91 23800 5.8 28900 5.66 34900 5.53 41900 5.44 49800 5.45 - - - -
30 14000 7.33 17500 7.4 21600 7.35 26400 7.23 32000 7.06 38500 6.9 45900 6.77 54200 6.73 63600 6.81
40 - - 15600 9.09 19500 9.17 24000 9.12 29100 8.98 35100 8.8 41800 8.61 49400 8.45 58000 8.37
50 - - - - - - 21200 11. 37 25900 11. 32 31300 11.19 37400 11 44300 10.8 52000 10.62
60 - - - - - - - - - - 27000 14.11 32400 13.99 38600 13.8 45600 13.59
63 - - - - - - - - - - - - 30900 15.01 36800 14.84 43600 14.63
6000 rpm
100
20 - - 31800 10.16 38500 10.16 46500 10.1 55900 10.08 66800 10.19 79400 10.5 - - - -
30 - - 29300 12.93 35900 13.02 43600 12.96 52600 12.83 63000 12.72 74900 12.73 88500 12.92 103800 13.41
40 - - 26400 15.75 32600 16.07 39800 16.13 48200 16.02 57800 15.82 68900 15.63 81400 15.54 95600 15.62
50 - - - - - - 35200 19.49 42600 19.53 51300 19.37 61200 19.12 72500 18.86 85400 18.67
60 - - - - - - - - - - 43500 23.26 52100 23.07 62000 22.77 73400 22.44
63 - - - - - - - - - - - - - - - - - -
VZH170BJ
1500 rpm
25
20 - - 12300 3.23 14800 3.1 17800 2.96 21200 2.81 25200 2.64 29700 2.45 - - - -
30 - - 10800 4.37 13200 4.23 16000 4.1 19300 3.97 23000 3.82 27300 3.66 32200 3.48 37800 3.26
40 - - 9200 5.65 11500 5.49 14100 5.36 17200 5.24 20700 5.13 24700 5 29300 4.87 34500 4.71
50 - - - - - - 12100 6.91 14900
6.8 18200 6.71 21900 6.62 26100 6.53 30900 6.43
60 - - - - - - - - - - 15400 8.72 18800 8.67 22700 8.63 27100 8.59
63 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 22700 8.5 28000 8.34 34400 8.17 41900 7.98 50700 7.75 61000 7.45 72800 7.09 - - - -
30 20300 10.58 25400 10.45 31400 10.32 38400 10.18 46600 10.02 56200 9.82 67200 9.56 79800 9.22 94100 8.8
40 - - 22700 12.96 28200 12.85 34700 12.75 42200 12.64 50900 12.5 61000 12.32 72600 12.09 85700 11.77
50 - - - - - - 30600 15.93 37400 15.85 45200 15.76 54200 15.64 64700 15.48 76600 15.26
60 - - - - - - - - - - 39000 19.85 46900 19.76 56200 19.65 66900 19.5
63 - - - - - - - - - - - - 44800 21.2 53700 21.1 64000 20.96
6000 rpm
100
20 - - 46700 14.95 57200 15.07 69500 15.01 83900 14.74 100600 14.2 119900 13.33 - - - -
30 - - 42500 18.02 52500 18.27 64200 18.43 77900 18.44 93700 18.25 111800 17.8 132500 17.06 156000 15.95
40 - - 38000 21.87 47400 22.14 58300 22.38 71000 22.55 85600 22.59 102500 22.44 121700 22.07 143600 21.41
50 - - - - - - 51600 27. 32 63100 27.52 76400 27.67 91700 27.71 109300 27.58 129400 27. 24
60 - - - - - - - - - - 66100 33.96 79800 34.05 95600 34.05 113900 33.91
63 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 11.1 K Presented data are for models with motor voltage code J
Tc: Condensing temperature in °C Subcooling = 8.3 K
Qo: Cooling capacity in W Pe: Power input in kW
