Technical specications
Capacity at ARI rating conditions - High pressure ratio - VZH088AG - VZH117AG - VZH170AG
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088AG
1500 rpm
25
20 - - 5700 1.47 7100 1.54 8600 1.62 10400 1.68 12500 1.67 14900 1.55 - - - -
30 - - 5200 2.04 6500 2.01 7900 2.03 9700 2.08 11600 2.1 13900 2.07 16400 1.95 19200 1.69
40 - - 4600 2.92 5800 2.74 7200 2.66 8800 2.65 10700 2.67 12700 2.69 15000 2.65 17600 2.54
50 - - - - 5100 3.79 6400 3.57 7800 3.47 9500 3.44 11300 3.46 13400 3.47 15800 3.45
60 - - - - - - - - 6600 4.59 8100 4.47 9700 4.45 11600 4.47 13600 4.5
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 12000 4.19 14700 4.26 17900 4.34 21700 4.42 26100 4.53 31200 4.65 37100 4.8 - - - -
30 10600 5.04 13100 5.11 16200 5.18 19700 5.26 23900 5.36 28600 5.47 34100 5.6 40300 5.75 47300 5.93
40 - - 11700 6.21 14600 6.27 17800 6.34 21600 6.42 26000 6.51 31000 6.61 36800 6.74 43200 6.89
50 - - - - 12900 7.75 15800 7.79 19300 7.84 23200 7.91 27700 7.98 32900 8.08 38800 8.19
60 - - - - - - - - 16600 9.77 20100 9.8 24100 9.84 28700 9.89 34000 9.96
68 - - - - - - - - - - - - 21300 11.76 25600 11.78 30400 11.81
6000 rpm
100
20 - - 24000 7.65 29200 7.96 35400 8.31 42700 8.71 51100 9.18 60700 9.72 - - - -
30 - - 21800 9.04 26800 9.28 32700 9.56 39500 9.88 47400 10.25 56400 10.68 66700 11.18 78300 11.77
40 - - 19800 10.85 24400 11.02 29800 11.21 36100 11.44 43300 11.71 51600 12.02 61000 12.4 71700 12.85
50 - - - - 21800 13.35 26600 13.46 32200 13.59 38700 13.74 46100 13.94 54600 14.18 64200 14.49
60 - - - - - - - - 27900 16.5 33500 16.54 40000 16.61 47400 16.72 55900 16.87
68 - - - - - - - - - - - - - - - - - -
VZH117AG
1500 rpm
25
20 - - 7700 1.93 9500 2.03 11600 2.13 14000 2.2 16800 2.19 20000 2.04 - - - -
30 - - 6900 2.68 8700 2.64 10700 2.67 13000 2.73 15600 2.76 18600 2.72 22000 2.56 25800 2.22
40 - - 6100 3.83 7800 3.59 9700 3.49 11900 3.48 14300 3.51 17100 3.53 20200 3.49 23700 3.33
50 - - - - 6800 4.97 8500 4.69 10500 4.55 12700 4.52 15200 4.54 18000 4.56 21200 4.54
60 - - - - - - - - 8900 6.02 10800 5.88 13100 5.84 15500 5.87 18300 5.92
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 16200 5.5 19800 5.59 24000 5.69 29100 5.81 35000 5.95 41900 6.11 49700 6.3 - - - -
30 14200 6.63 17600 6.71 21700 6.81 26500 6.91 32000 7.04 38500 7.18 45800 7.35 54100 7.55 63600 7.78
40 - - 15700 8.16 19500 8.24 23900 8.33 29100 8.43 34900 8.55 41700 8.69 49300 8.85 58000 9.05
50 - - - - 17300 10.17 21300 10.23 25800 10.3 31100 10.38 37200 10.48 44100 10.61 52000 10.76
60 - - - - - - - - 22300 12.83 27000 12.87 32400 12.92 38500 12.99 45600 13.09
68 - - - - - - - - - - - - 28700 15.44 34300 15.47 40800 15.51
6000 rpm
100
20 - - 32300 10.05 39200 10.45 47500 10.91 57300 11.44 68500 12.05 81500 12.76 - - - -
30 - - 29300 11. 88 36000 12.19 43900 12.55 53000 12.97 63600 13.46 75700 14.02 89500 14.68 105100 15.45
40 - - 26500 14.25 32800 14.47 40000 14.73 48500 15.02 58200 15.37 69300 15.79 81900 16.29 96200 16.88
50 - - - - 29200 17.54 35800 17.68 43300 17.84 52000 18.05 61900 18.31 73300 18.63 86200 19.03
60 - - - - - - - - 37400 21.67 45000 21.72 53600 21.81 63600 21.95 75000 22.16
68 - - - - - - - - - - - - - - - - - -
VZH170AG
1500 rpm
25
20 - - 11900 3.1 14500 3.07 17500 3.05 2110 0 2.98 25200 2.84 29900 2.6 - - - -
30 - - 10700 4.02 13100 3.96 16000 3.95 19400 3.95 23300 3.93 27700 3.85 32700 3.68 38400 3.39
40 - - 9300 5.29 11600 5.11 14300 5.03 17400 5.01 21000 5.02 25000 5.03 29700 5 34900 4.89
50 - - - - 9900 6.72 12300 6.5 15100
6.38 18300 6.34 21900 6.35 26100 6.37 30800 6.36
60 - - - - - - - - 12500 8.24 15200 8.07 18400 8 22100 7.99 26300 8.01
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 24500 7.46 29300 7.63 35200 7.81 42400 7.98 50800 8.12 60700 8.19 72100 8.18 - - - -
30 21800 9.38 26500 9.47 32200 9.61 39000 9.78 46900 9.94 56200 10.08 66900 10.17 79100 10.2 93100 10.12
40 - - 24000 11.86 29300 11.9 35500 12.01 42800 12.15 51300 12.3 61100 12.44 72400 12.54 85200 12.58
50 - - - - 26200 14.82 31700 14.81 38200 14.87 45800 14.97 54500 15.1 64600 15.23 76200 15.33
60 - - - - - - - - 32900 18.23 39400 18.23 47000 18.3 55900 18.4 66100 18.51
68 - - - - - - - - - - - - 41000 21.33 49000 21.37 58200 21.45
6000 rpm
100
20 - - 48200 13.28 58500 13.87 70800 14.52 85300 15.27 102100 16.18 121500 17. 3 - - - -
30 - - 43000 16.27 52900 16.84 64400 17. 39 77900 17.97 93500 18.62 111400 19.39 131800 20.34 154900 21.51
40 - - 38900 19.83 48100 20.45 58800 20.97 71200 21.44 85400 21.91 101800 22.42 120400 23.03 141400 23.78
50 - - - - 43400 24.85 53100 25.42 64200 25.86 77000 26.22 91700 26.55 108400 26.89 127300 27.29
60 - - - - - - - - 56400 31.4 67700 31.73 80600 31.94 95400 32.09 112200 32.23
68 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 11.1 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °C Subcooling = 8.3 K
Qo: Cooling capacity in W Pe: Power input in kW
12 FRCC.PC.023.A8.02
Application Guidelines
