Technical specications
Capacity at EN12900 rating conditions - High pressure ratio - VZH088AG - VZH117AG - VZH170AG
Models
rpm
rps
To -25 -20 -15 -10 -5 0 5 10 15
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088AG
1500 rpm
25
20 - - 5400 1.47 6600 1.54 8100 1.62 9800 1.68 11800 1.67 14000 1.55 - - - -
30 - - 4800 2.04 6000 2.01 7400 2.03 9000 2.08 10800 2.1 12900 2.07 15300 1.95 17900 1.69
40 - - 4200 2.92 5300 2.74 6600 2.66 8100 2.65 9800 2.67 11700 2.69 13800 2.65 16200 2.54
50 - - - - 4500 3.79 5700 3.57 7000 3.47 8500 3.44 10200 3.46 12100 3.47 14300 3.45
60 - - - - - - - - 5700 4.59 7000 4.47 8500 4.45 10100 4.47 11900 4.5
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 1130 0 4.19 13800 4.26 16800 4.34 20300 4.42 24500 4.53 29300 4.65 34800 4.8 - - - -
30 9800 5.04 12200 5.11 15000 5.18 18300 5.26 22200 5.36 26700 5.47 31800 5.6 37600 5.75 44200 5.93
40 - - 10700 6.21 13300 6.27 16300 6.34 19900 6.42 23900 6.51 28500 6.61 33800 6.74 39800 6.89
50 - - - - 1150 0 7.75 14200 7.79 17300 7. 8 4 20900 7.91 25000 7.98 29700 8.08 35000 8.19
60 - - - - - - - - 14400 9.77 17500 9.8 21000 9.84 25000 9.89 29600 9.96
68 - - - - - - - - - - - - 17300 11.76 20800 11.78 24800 11. 81
6000 rpm
100
20 - - 22500 7.65 27400 7.96 33200 8.31 40000 8.71 48000 9.18 57100 9.72 - - - -
30 - - 20200 9.04 24900 9.28 30400 9.56 36700 9.88 44100 10.25 52500 10.68 62100 11.18 73000 11.77
40 - - 18100 10.85 22300 11.02 27300 11.21 33100 11.44 39800 11.71 47400 12.02 56200 12.4 66000 12.85
50 - - - - 19500 13.35 23900 13.46 29000 13.59 34900 13.74 41600 13.94 49300 14.18 58000 14.49
60 - - - - - - - - 24200 16.5 29100 16.54 34800 16.61 41300 16.72 48800 16.87
68 - - - - - - - - - - - - - - - - - -
VZH117AG
1500 rpm
25
20 - - 7200 1.93 8900 2.03 10800 2.13 13100 2.2 15800 2.19 18800 2.04 - - - -
30 - - 6400 2.68 8000 2.64 9900 2.67 12100 2.73 14500 2.76 17300 2.72 20500 2.56 24100 2.22
40 - - 5600 3.83 7100 3.59 8900 3.49 10900 3.48 13100 3.51 15700 3.53 18600 3.49 21800 3.33
50 - - - - 6100 4.97 7700 4.69 9400 4.55 11500 4.52 13700 4.54 16300 4.56 19100 4.54
60 - - - - - - - - 7700 6.02 9400 5.88 1140 0 5.84 13500 5.87 16000 5.92
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 15100 5.5 18500 5.59 22500 5.69 27300 5.81 32900 5.95 39300 6.11 46700 6.3 - - - -
30 13100 6.63 16400 6.71 20200 6.81 24600 6.91 29800 7.04 35800 7.18 42600 7.35 50400 7. 55 59300 7.78
40 - - 14400 8.16 17900 8.24 21900 8.33 26700 8.43 32100 8.55 38300 8.69 45400 8.85 53400 9.05
50 - - - - 15500 10.17 19100 10.23 23200 10.3 28000 10.38 33600 10.48 39900 10.61 47000 10.76
60 - - - - - - - - 19300 12.83 23400 12.87 28100 12.92 33600 12.99 39800 13.09
68 - - - - - - - - - - - - 23200 15.44 27900 15.47 33300 15.51
6000 rpm
100
20 - - 30200 10.05 36800 10.45 44600 10.91 53700 11.4 4 64400 12.05 76600 12.76 - - - -
30 - - 27200 11.88 33400 12.19 40700 12.55 49300 12.97 59200 13.46 70500 14.02 83400 14.68 98000 15.45
40 - - 24200 14.25 30000 14.47 36700 14.73 44500 15.02 53400 15.37 63700 15.79 75400 16.29 88600 16.88
50 - - - - 26200 17.54 32100 17.68 38900 17.84 46800 18.05 55800 18.31 66100 18.63 77900 19.03
60 - - - - - - - - 32400 21.67 39000 21.72 46700 21.81 55400 21.95 65500 22.16
68 - - - - - - - - - - - - - - - - - -
VZH170AG
1500 rpm
25
20 - - 11200 3.1 13600 3.07 16400 3.05 19800 2.98 23600 2.84 28100 2.6 - - - -
30 - - 9900 4.02 12200 3.96 14900 3.95 18000 3.95 21600 3.93 25800 3.85 30500 3.68 35800 3.39
40 - - 8500 5.29 10600 5.11 13100 5.03 16000 5.01 19200 5.02 23000 5.03 27300 5 32200 4.89
50 - - - - 8900 6.72 11000 6.5 13600
6.38 16400 6.34 19800 6.35 23600 6.37 27900 6.36
60 - - - - - - - - 10800 8.24 13200 8.07 16000 8 19200 7.99 22900 8.01
68 - - - - - - - - - - - - - - - - - -
3600 rpm
60
20 22900 7.46 27500 7.63 33000 7.81 39700 7.98 47700 8.12 57000 8.19 67700 8.18 - - - -
30 20200 9.38 24600 9.47 29900 9.61 36200 9.78 43600 9.94 52300 10.08 62300 10.17 73800 10.2 86800 10.12
40 - - 21900 11.86 26800 11.9 32500 12.01 39300 12.15 47100 12.3 56200 12.44 66600 12.54 78500 12.58
50 - - - - 23400 14.82 28500 14.81 34300 14.87 41200 14.97 49200 15.1 58400 15.23 68900 15.33
60 - - - - - - - - 28500 18.23 34200 18.23 40900 18.3 48700 18.4 57700 18.51
68 - - - - - - - - - - - - 33200 21.33 39800 21.37 47400 21.45
6000 rpm
100
20 - - 45100 13.28 54800 13.87 66400 14.52 80100 15.27 95900 16.18 11420 0 17.3 - - - -
30 - - 39900 16.27 49000 16.84 59800 17.39 72400 17.97 87000 18.62 103700 19.39 122800 20.34 144500 21.51
40 - - 35600 19.83 44100 20.45 53900 20.97 65300 21.44 78500 21.91 93500 22.42 110800 23.03 130300 23.78
50 - - - - 38900 24.85 47700 25.42 57800 25.86 69400 26.22 82700 26.55 97800 26.89 115000 27.29
60 - - - - - - - - 48900 31.4 58800 31.73 70100 31.94 83100 32.09 97900 32.23
68 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °C Superheat = 10 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °C Subcooling = 0 K
Qo: Cooling capacity in W Pe: Power input in kW
11FRCC.PC.023.A8.02
