Data Aire DAP III User Manual

15
6-12 SNMPv2 Manager 1 Address
6-13 SNMPv2 Manager 1 Notifi cations
6-14 SNMPv2 Manager 2 Address
6-15 SNMPv2 2 Notifi cations
Group 7 – Calibration
7-1 Calibrate temperature sensor
7-2 Calibrate humidity sensor
7-3 Calibrate discharge air temperature sensor
7-4 Calibrate CW temperature sensor
Group 8 – Setback
(Only displayed when RFM mode is active.)
8-1 Day schedule
8-2 Override enable
8-3 Override time
8-4 Setup cool
8-5 Setback reheat
8-6 Setup dehumidifi cation
8-7 Setback humidifi cation
8-8 Monday schedule
8-9 Tuesday schedule
8-10 Wednesday schedule
8-11 Thursday schedule
8-12 Friday schedule
8-13 Saturday schedule
8-14 Sunday schedule
Group 9 – Diagnostic
9-1 Test buttons
9-2 Check power supply
9-3 Test relays
9-4 Test analog outputs
9-5 Test digital inputs
9-6 Test environmental sensors
9-7 View anticipation humidity setpoint
9-8 Test audio alarm
9-9 Test RS-485 network card
9-10 Test watchdog reset circuit
Group 10 – Analog Group 10 - (Only appears when an Analog Module is connected.)
10-1 Select sensor 1 name
10-2 Specify sensor 1 units of measure
10-3 Specify sensor 1 signal range
10-4 Specify sensor 1 minimum value
10-5 Specify sensor 1 maximum value
10-6 Set Sensor 1 calibration
10-7 Select sensor 2 name
10-8 Specify sensor 2 units of measure
10-9 Specify sensor 2 signal range
10-10 Specify sensor 2 minimum value
10-11 Specify sensor 2 maximum value
10-12 Set sensor 2 calibration
10-13 Select sensor 3 name
10-14 Specify sensor 3 units of measure
10-15 Specify sensor 3 signal range
10-16 Specify sensor 3 minimum value
