DATA PRECISION 1350 User Manual

DC CURRENT CALIBRATION (Select DCmA Mode)
Range Input
Spec. Limits
Measurements
100.OpA
+190.OpA
+191.1
+188.9
l.OOOmA +1.900nA
+1.911
+1.869
lO.OOmA
+19.00mA
+19.11
+18.89
' /f?f
100.0mA
+190.0mA +191.1
+188.9
1000mA +1000mA
+1006.
+ 994.
lOA +10A
+10.06
+ 9.94
CURRENT CALIBRATION (Select ACnA Mode)
Range
Input
Spec. Limits
Measurements
1000mA 1000mA
500Hz
1010.
990.
J'j-
ELEVATED TEMPERATURE CHECKS
Measurements eure taken at 45°C after 6 hours.
Range Input Spec, Limits
Measurements
l.OV (DC) 0 + .002
-.002
l.OV (DC)
+1.000VDC
+1.005
+ .995
l.OV (AC)
1.OOOVAC
lOOHz
1.012
.986
COPYRIGHT 1978
Printed in U.S.A.
DATA PRECISION CORP.
FINAL ACCEPTANCE TESTS
Model No. 1351
Serial No.
Final ReportAcceptemce By
Date /iyi9 S'3
Before performing any measurements« lift 12 inches above horizontal wooden
bench top. Let the chassis drop back freely to the bench top.
VISUAL INSPECTION
Visual inspection should assure the mechanical integrity of the meter.
DC OVERVOLTAGE
Select the 100.OmV range. Apply +1000.0 volts to the input terminals. Af^^ j j
S seconds, switch up to the lOOOV range, remove input voltage.
DC VOLTAGE CALIBRATION (Select DCV Mode)
^ S
Range Input
Spec. Limits
Measurements
100.OmV 0
+00.1
-00.1
/oo./J
100.OmV
+100.OmV +100.2
+ 99.8
100.OmV
+190.OmV
+190.3
+189.7
100.OmV
-190.OmV
-190.3
-189.7
" / ^
l.OOOV
+1.900V +1.903
+1.897
' /fM
lO.OOV
+19.00V
1
+19.03
+18.97
i
100.OV
+190.OV
+190.3
+189.7 *
lOOOV
+1000V
+1002.
+ 998.
62-2006
