DataCard SD160 User Manual

XPS Card Printer Driver User’s Guide 117
Emboss Example
~EM%2;401;843;0001 3416 7890 1286
~EM%10;401;650;0001
~EM%1;800;480;2007
~EM%1;1600;480;10/17
~EM%1;401;328;Janice Holloway
The embosser escapes define emboss and
indent data to produce the following card. The
sample card shows the location of each
embossed element. The escapes can be placed
anywhere on the card design that does not
contain data to be printed.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
