DataCard SD160 User Manual

XPS Card Printer Driver User’s Guide A-5
Install the Card Printer Driver on the Client PC
The client PC must be running the Windows 7, Windows 8.1, or Windows 10 64-bit operating
system. Refer to “Printer Sharing Requirements” on page 28 for a list of supported host/client
operating system combinations.
The following instructions may vary slightly based on the operating system of the client PC.
1. Make sure that the Card Printer Driver is installed and set up on the host PC.
2. Log on to the client PC with a user account that has administrator privileges and matches an
account and password on the host PC.
 Start at the Login screen of the client PC and review the user names displayed. Look for a
user with administrator access that matches a user name on the host PC. If one is not
listed, set up a user account and password on the client PC to match an administrator
account from the host PC.
OR
 Log on to the host PC from the client PC using a network access as follows:
 Use Windows File Explorer or My Computer to locate the host PC.
 Select the host PC. The Enter Network Password dialog box displays.
 Enter your password and click OK. The host PC desktop displays.
You must log on to the host PC across the network by using a different user
account than was used to install the printer on the host.
After you log on to the host PC using the network, keep the window open until
the installation completes.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
