DataCard SD160 User Manual

XPS Card Printer Driver User’s Guide 83
Use a User-Defined Topcoat Bitmap
User-defined bitmaps allow you to apply topcoat to a card in custom patterns or shapes when the
predefined blocking areas and escapes are not sufficient. The bitmap files are installed as part of
the Card Printer Driver Installation in the C:\CardPrinter folder. If you previously used an older-
generation desktop printer, the bitmap files may already be on your PC.
The topcoat bitmap used depends on the card side and orientation you specify.
Side Orientation Bitmap File
1Portrait CRDPortTopcoatFront.bmp
2 Portrait CRDPortTopcoatBack.bmp
1 Landscape CRDLandTopcoatFront.bmp
2 Landscape CRDLandTopcoatBack.bmp
If the bitmap files are already installed on your computer, a new driver installation or
update does not overwrite the existing files.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
