DK-40 USER MANUAL V2.6 (02.08.2011)
K13D01-E - 29 -
No Description Adjustment Range Factory set
P73 Input1 configuration register
0 ... 2047
Refer chapter 7 for more details.
18
P74 Input 2 configuration
register
0 ... 2047
Refer chapter 7 for more details.
28+512=540
P75 Input 3configuration register
0 ... 2047
Refer chapter 7 for more details.
8+512=520
P76 Input 4configuration register
0 ... 2047
Refer chapter 7 for more details.
16+256+=1808
P77
Pressure 2 Input
Configuration
0: Disabled
1: Pressure switch
2: Analog transducer
If this parameter is set to 0 or 1,
parameters P78 ... P82 will not be
displayed.
0
P78
Top range pressure 2
transducer
4.2 ... 99.9 Bar 15.0 bar
P79
High Pressure Sensor 2
Alarm Limit
3.7 ... (P78-0.5) 8.8 bar
P80
Differential pressure alarm
limit (press1 – press2)
-10.0 ... +10.0 0.5 bar
P81
Differential pressure alarm
delay
1 ... 600 10 sec
P82 Offset pressure transducer 2 -2:+2 0 bar
