Datalogic Lynx Instruction Manual

HOW TO USE THIS MANUAL
CONNECTIONS
To make system connections see par. 1.3.
CONFIGURATION
You can configure the LYNX™ reader in the following ways:
• reading the programming barcode symbols in this manual
configuration commands and their relative arguments are read individually using
the symbols in this manual. See chapter 2, Appendix B and Appendix C.
• using the Lynx™ Configuration Tools software utility
programming the reader is accomplished by selecting configuration commands or
printing them through a user-friendly graphical interface running on the PC. These
commands are sent to the reader over the current communication interface; or
they can be printed to be read. Install the Datalogic VisualSetup program from the
CD-ROM provided.
DESCRIPTIONS
• For information on how to use the device read chapter 1.
• Explanations for some of the more complex barcode reading parameters
are given next to the relative parameter in chapter 2.
