Datalogic Lynx Instruction Manual

GETTING STARTED
1
1.4.3 Image Capturing
Lynx™ can also function as a camera by capturing images of labels, signatures, and
other items.
In order to capture an image, the user should read a Capture Image code (see par
2.12), then point at the image subject and pull the trigger. This way, the image will be
captured and sent to the host PC. Lynx™ then returns to normal operation. To
o position the reader from the object (ensure the
the RS232 interface has been selected, the image will be transferred to the host PC
via XMODEM_1K protocol.
capture another image you must read another Capture Image Code of the same or a
different Preset Configuration.
You can use the aiming system t
reader is about centered over the target). Adjust the distance at which you are
holding the reader (see Figure 5).
If
Image capturing is not available in Wed
NOTE
ge and USB Keyboard
Emulation interfaces and is not compatible with Autoscanning nor
when the Software trigger type is selected.
Up to four different and independent Image Presets can be defined (see par. 2.13).
For each Image Preset you may set up to three Basic Configuration Parameters, and
p to five Advanced Configuration Parameters. Therefore an image is processed
of parameters.
VGA Resolution (640 x 480 pixels) (default),
or JPEG images it is possible to define the Image Quality level to address tradeoff
An image portion (Window), instead of an entire image, can be captured. This
parameter is generally used for particular fixed reading position applications.
u
before being sent to the Host, according to a preset group
Basic Configuration Parameters
The Image file formats supported are: BMP, TIFF, JPEG (default).
Two resolution options are available:
and CIF Resolution (320 x 240 pixels). The lower resolution setting yields smaller file
sizes, so the transfer time decreases.
F
between image file size and quality.
Advanced Configuration Parameters
7
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France
Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
