Datalogic Lynx Instruction Manual

LYNX™
2
2 CONFIGURATION USING BARCODE SYMBOLS
This section describes the programming method of using configuration barcode
symbols to program your reader. By using the LYNX™ reader to read/decode these
special configuration symbols, you can configure, and obtain information from its
system software.
When you are reading configuration barcode symbols, carefully aim the LYNX™ 2D
reader to avoid reading adjacent symbols.
The configuration barcode symbols in this chapter are divided into logical
sections according to the type of configuration required, (RS232 configuration,
Code selection, etc.). If arguments are required with a command, you can read
additional barcode labels (typically digits) from Appendix C.
To configure your reader:
1. Open the folded page in
Appendix C the Hex/Numeric table and keep it open
during the device configuration.
2. Read the Enter Configuration code ONCE, available on the folded page in
Appendix C or in par. 2.2.1.
3. Modify the desired parameters in one or more sections by reading the parameter
code and selecting the value from the Hex/Numeric table or by following the
given procedures.
4. Read the Exit and Save Configuration code
ONCE, available on the folded
page in Appendix C or in par. 2.2.1.
Example for step 3:
To set the maximum length of characters in a Code 39 barcode symbol that the
reader will decode to 32:
• first read the Maximum Length symbol for Code 39 on page 50
• then read the symbol for the digit "3" and lastly the symbol for the digit "2" in
Appendix C.
14
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France
Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
